18 / 16t-g Gravel Pump Slurry Pump Manufacturer

18 / 16t-g gravel pump is a horizontal centrifugal pump with single casing structure.

Special clamp is used to clamp the pump body and cover. The outlet direction of the pump can be at any position of 360 degrees, so it is easy to install and use.

The bearing assembly adopts cylindrical structure, which is easy to adjust the clearance between impeller and pump body, and can be removed as a whole during maintenance. The bearings are lubricated with grease.

Introduction to performance parameters of 18 / 16t-g gravel pump

Flow rate: 8600 M / h

Head (H): 9-48m

Speed (n): 250-500 rpm

Maximum efficiency: 60-72

NPSH R: 3-6.0

Suction diameter: 450mm

Discharge diameter: 400mm

Maximum particle size: 254MM

Price: 364285 (this price is for reference only)

18 / 16t-g gravel pump model meaning:

18: Inlet diameter

16: Outlet diameter

T: Bracket type

GH: high lift

18 / 16t-g gravel pump scope of application:

Gravel pump has the characteristics of wide flow channel, good cavitation performance, high efficiency, wear resistance and so on. It is mainly used for the continuous transportation of strong abrasive materials whose particles are too large to be transported by ordinary slurry pump.

It is suitable for dredging, sand suction, river dredging, river sand mining and metal smelting slag transportation.
