High Pressure Piston Air Compressor 30bar Natural 7.5kw 10hp 116psi Fusheng Style Piston Air Compressor in Shanghai
- SHANGHAI
- T/T Credit Card
You May Like
-
High Pressure Piston Air Compressor 30 BAR
-
High Quality Small High Pressure Air Compressor Prices
-
HOT Sale!!! 30bar Air Compressor/Hengda Air Compressor
-
PET Blowing Machine Air Compressor Price/High Pressure Air Compressor(30bar)
-
Air Compressor/Piston Air Compressor/Oil Less Air Compressor
-
PET Industry High Pressure Piston Compressor
Product Details
| Brand Name | Hengda | Place of Origin | Jiangsu, China | |
| Model Number | 4-WH-6.0/30 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High pressure air compressor, piston air compressor 30bar High pressure piston air compressor 30bar natural gas compressors for sale/ 7.5kw 10hp 116psi fusheng style piston air compressor in shanghai
1. Main data
Equipment Model | Free Air Delivery (M3/min) | Pressure (Bar) | Power (Kw) | Rotating speed (r/min) | Size(mm) | Weight (Kg) |
| 4-WH-6.0/30 | 6.0 | 30 | 4*18.5 | 790 | 2020*1570*200 | 3500 |
Model | Air capacity (M3/min) | Working pressure (Bar) | Power(Kw) | Speed(r.p.m) | Weight(Kg) |
VH-0.7/30 | 0.7 | 30BAR | 7.5 | 680 | 310 |
WH-1.0/30 | 1.0 | 11 | 600 | 430 | |
WH-1.2/30 | 1.2 | 15 | 760 | 450 | |
WH-1.5/30 | 1.5 | 18.5 | 790 | 520 | |
WH-2.0/30 | 2.0 | 22 | 670 | 610 | |
WH-2.35/30 | 2.35 | 25 | 760 | 620 | |
2-WH-3.0/30 | 3.0 | 2*18.5 | 790 | 1150 | |
3-WH-3.6/30 | 3.6 | 3*15 | 700 | 1580 | |
VH-0.17/35 | 0.17 | 35BAR | 2.2 | 660 | 110 |
VH-0.65/35 | 0.65 | 9.0 | 605 | 420 | |
WH-1.1/35 | 1.1 | 15 | 900 | 475 | |
WH-2.0/35 | 2.0 | 22 | 670 | 615 | |
WH-2.2/35 | 2.2 | 25 | 735 | 600 | |
VH-0.3/40 | 0.3 | 40BAR | 5.5 | 500 | 290 |
WH-1.0/40 | 1.0 | 11 | 790 | 470 | |
49SH-2.6/40 | 2.6 | 25 | 625 | 900 | |
49SH-3.0/40 | 3.0 | 30 | 695 | 920 | |
2-49SH-6.0/40 | 6.0 | 2*30 | 695 | 2100 | |
4-WH-4.0/40 | 4.0 | 4*11 | 790 | 2400 | |
6-WH-6.0/40 | 6.0 | 6*11 | 790 | 3600 |
2. Inspection method:
CAGI
3. Inspection standard:
-AISI
-AMS
-ANSI
-ASME
-ASTM
-AGMA
-AGMA
-NEMA
-VDI
-CAGI-NPEUROP
-MS
4.High pressure air compressor
- The compressor can remove waste and dirt automatically by after cooling system. High-quality air out end with a special, highly effective air cooling chiller of advanced design.
- Market leader “Herbiger” main air valve with large capacity. Its high efficiency characteristic ensures the stable running of the compressor.put due to economical dirt removal system in 3 stages.
- The compressor is equipped with a special,highly effective air cooling chiller of advanced design
5.ELECTRICS FOR MACHINES
If the equipment fails due to the quality of the machine during one year, we will provide replacement and the repair Free of Charge. after One Year customer must pay for Spare Parts, we will provide long-term technical assistance.
Workers must operate the machines according to the design of the machine. Faygo Machinery will not be responsible for accidents which are caused by improper operation of workers.
