Remote Control Double Drum Roller RWYL301

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ROADWAY	Place of Origin	China
Model Number	RWYL301	Type	Other, Remote-controlled groove compactor
After-sales Service Provided	Engineers available to service machinery overseas	Weight	848kg
Dimension(LWH)	1245 × 865 × 1252mm	Condition	New
Power(W)	13.0hp / 3600rpm	Grade Ability	30%
Travel Speed	1.2km / h(low); 3.6km / h(high)	Static Linear Pressure	50.2 / 52.2 N / cm

Overview:

You can rest and work, greatly liberating staff.

Features:

· Remote control system, automatic control, stable performance.

· Italian hydraulic pump.

Danfoss hydraulic motor.

· Vickers solenoid control valve.

· HONDA gasoline engine.

· Hydraulic steering.

· Special resin wear-resistant scraper, long wear life.

· Stainless steel sprinkler pipe is more conducive to flowing water.

· Ultra-large-volume plastic water tank, reducing the number of water refills and improving work efficiency.

VIDEO:/lnBjjKmloo-llijKBljlmSRnikqrrrjoknlor-11e98c27214b443ea967527e50fa87f1

Technical Parameters

Run		Fuel tank volume	6.5L
Speed	1.2km / h(low); 3.6km / h(high)	Lubricant L	1.1L
Turning radius	15 °	Fuel consumption	374g / kWh
Climbing capacity in theory	30%	Dimension
Compaction		Width of steel drum	680mm
Static load	50.2 / 52.2 N / cm	Diameter of steel drum	355mm
Nominal amplitude	0.5mm	Tread	650mm
Vibration frequency	60Hz	Total length	1120mm
Exciting force	20kN	Total width	755mm
Engine		Total height	1100mm
Model	HONDA GX390	Packing size	1245 × 865 × 1252mm
Type	Gasoline engine, air-cooled, single cylinder	Weight
Power	13.0hp / 3600rpm	Working weight	848kg
