SHORE A/C/D/O Portable Durometer

SHORE A/C/D/O Portable Durometer

SHORE A Durometer

Function:

SHORE A - widely used to test common rubber, complex rubber, soft rubber, elastomers, leather, wax and so on. It is available in DIN 53505, ASTM D2240, ISO/R868, JIS R7215.Executive standard - GB/T531-99,GB2411-80, HG/T2489-93,JJG304-2003.

Specification:

High resolution;

With facility, easy to operate;

Use by handy or by test stand(HLX-AC);

Test range: 0-100 HA;

Available test range: 10-90 HA ;

Dimension: 115*60*25(mm);

Stroke: 2.5 mm;

Tip dimension: Φ0.79mm;

Net weight: 0.5kgs;

SHORE A Durometer (Peak hold)

Function:

SHORE A - widely used to test common rubber, complex rubber, soft rubber, elastomers, leather, wax and so on. It is available in DIN 53505, ASTM D2240, ISO/R868, JIS R7215.Executive standard - GB/T531-99,GB2411-80, HG/T2489-93,JJG304-200

Specification:

High resolution;

With facility, easy to operate;

Use by handy or by test stand (HLX-AC);

Test range: 0-100 HA;

Available test range: 10-90 HA ;

Dimension: 115*60*25(mm);

Stroke: 2.5 mm;

Tip dimension: Φ0.79mm;

Net weight: 0.5kgs;

SHORE C Durometer

Function:

SHORE C Durometer is widely used in testing of various kinds of foam, sponge, micro porous material and so on. It is available in HG/T2489-93.

Specification:

High resolution;

With facility, easy to operate;

Use by handy or by test stand(HLX-AC);

Test range: 0-100 HW;

Available test range: 10-90 HW ;

Dimension: 115*60*25(mm); S

troke: 2.5 mm;

Tip dimension: SR2.5mm;

Net weight: 0.5Kgs;

SHORE C Durometer (Peak hold)

Function:

SHORE C Durometer is widely used in testing of various kinds of foam, sponge, micro porous material and so on. It is available in HG/T2489-93.

Specification:

High resolution;

With facility, easy to operate;

Use by handy or by test stand (HLX-AC);

Test range: 0-100 HW;

Available test range: 10-90 HW ;

Dimension: 115*60*25(mm);

Stroke: 2.5 mm;

Tip dimension: SR2.5mm;

Net weight: 0.5Kgs;

SHORE D Durometer

Function:

SHORE D - widely used to test hard rubber, hard colophony, grass, plastic, print board, fiber and so on. It is available in DIN 53505, ASTM D2240,ISO/R868, JIS R7215.executive standard - GB/T531-99, GB2411-80,HG/T2489-93, JJG304-2003.

Specification:

High resolution;

With facility, easy to operate;

Use by handy or by test stand(HLX-D);

Test range: 0-100 HD;

Available test range: 10-90 HD ;

Dimension: 115*60*25(mm);

Stroke: 2.5 mm;

Tip dimension: SR0.1mm;

Net weight: 0.5Kgs;

SHORE D Durometer (Peak hold)

Function:

SHORE D - widely used to test hard rubber, hard colophony, grass, plastic, print board, fiber and so on. It is available in DIN 53505, ASTM D2240,ISO/R868, JIS R7215.executive standard - GB/T531-99, GB2411-80,HG/T2489-93, JJG304-2003.

Specification:

High resolution;

With facility, easy to operate;

Use by handy or by test stand(HLX-D);

Test range: 0-100 HD;

Available test range: 10-90 HD ;

Dimension: 115*60*25(mm);

Tip dimension: SR0.1mm

SHORE O Durometer

Function:

SHORE O Durometer is widely used in testing of various kinds of foam, sponge, micro porous material and so on. It is available in HG/T2489-93.

Specification:

High resolution;

With facility, easy to operate;

Use by handy or by test stand(HLX-AC);

Dimension: 115*60*25(mm);

Stroke: 2.5 mm;

Tip dimension: SR2.5mm;

Net weight: 0.5Kgs;
