Home > Products > Microscope > MIT100 Upright Binocular Metallurgical Microscope
MIT100 Upright Binocular Metallurgical Microscope
- T/T Credit Card
You May Like
-
Trinocular Stereo Microscope Model SZ680TP/SZ680T2L
-
SZ680-series Stereo Microscope Biological Research
-
SZ680/SZ780 Digital Usb Digital Usb Microscope Camera
-
SZ680/SZ780 Stereo Zoom/Dissecting/Digital Microscope
-
SZ650/ SZ680/SZ780 SZ Series Stereo Zoom Microscope With Digital Camera
-
SZ Series Zoom Stereo Microscope Trinocular
Product Details
| Brand Name | Drawell | Place of Origin | Shanghai, China | |
| Model Number | MIT100 |
Product Description
MIT100/200 Metallurgical Microscope
MIT100/200 Metallurgical Microscope Outfits
Items | Specification | MIT100 | MIT200 | |
Eyepiece | WF10×-18mm | * | * | |
Reticule Eyepiece WF 10×-18 mm (0.1mm) | * | * | ||
Long Working Distance Infinity Plan Objective (no cover glass) | LPL 5×/0.13 | W.D=24.23mm | * | * |
LPL 10×/0.25 | W.D=18.48mm | * | ||
LPL 20×/0.4 | W.D=8.35mm | # | * | |
LPL 40×/0.65 | W.D=3.90mm | # | # | |
LPL 50×/0.7 | W.D=1.95mm | * | * | |
LPL 80×/0.8 | W.D=0.85mm | # | # | |
LPL 100×/0.9 | W.D=1.00mm | # | # | |
Seidentopf Binocular Head | Inclined 30°,Rotatable 360°, Interpupilary Distance: 48 -75mm | * | * | |
Seidentopf Trinocular Head | Inclined 30°,Rotatable 360°, Interpupilary Distance: 48 -75mm Light Distribution 80:20 | # | # | |
Nosepiece | Quadplex | * | * | |
Mechanical Stage | Stage Size: 200×140mm, Travel : 76mm×52mm Coaxial Coarse and Fine Focusing Knobs ————————————————————————— Stage Size: 200×140mm, Travel : 78mm×35mm Coaxial Coarse and Fine Focusing Knobs |
* ——————————— * | ||
Reflection Illumination | 6V/20W Halogen Lamp | * |
| |
6V/30W Halogen Lamp |
| * | ||
Filter | Five-hole filter unit(blue, green, amber, grey, empty) | * | * | |
Polarizing Attachment | Analyzer/ Polarizer |
| # | |
C-mount | 1× | # | # | |
0.5X (Focus Adjustable) | # | # | ||
Note: "*"In Table Is Standard outfits, "#" Is Optional Accessories.
MIT100 Packing Size: 565mm×310mm×410mm Gross Weight: 9 kgs Net Weight: 6 kgs
MIT200 Packing Size: 570mm×275mm×450mm Gross Weight: 10.5 kgs Net Weight: 8 kgs
