Home > Products > Microscope > SMART-e320/500 Digital Optical Microscope Price
SMART-e320/500 Digital Optical Microscope Price
- shanghai
- T/T Credit Card
You May Like
-
BK-POL/POLF/POLR Digital Polarizing Microscope Binocular Polarizing Microscope
-
BK-5000 Series Electronic Binocular Biological Microscope
-
BK-FL2/FL4 Series Advanced Biological Fluorescence Microscope Price
-
BK-FL2/FL4 Series Biological Microscope Outfits Fluorescence Fluorescent Microscope With LED
-
BK-FL2 FL4 Series Fluorescence Biological Microscope Price
-
BK-FL2/FL4 Series Cheap Reflected-Light Fluorescence Microscope Magnification
Product Details
| Brand Name | Drawell | Place of Origin | Shanghai, China | |
| Model Number | SMART-e320/500 |
Product Description
SMART-e320/500 Digital Microscope Characteristics
* Dustproof, moisture-proof, built-in chip.
* Light distribution 20:80, eyepiece observation synchronized with digital imaging without switching.
* Built-in 3MP/5MP digital camera system,1/2’’CMOS color sequential scanning.
* USB2.0 connection without external power supply.
* Available for WINDOWS 2000/XP/7/Vista system.
SMART-e Digital Microscope Outfits
Items | Specification | SMART-e320 | SMART-e500 |
Eyepiece | WF 10X-20mm | YY | YY |
Infinity EPlan Objective | 4X | Y | Y |
10X | Y | Y | |
40X/0.65 (S) | Y | Y | |
100X/1.25 (Oil) (S) | Y | Y | |
Seidentopf Binocular Head | Inclined 30°,Rotatable 360°,Interpupilary Distance: 50-75mm | Y | Y |
Nosepiece | Quadplex | Y | Y |
Mechanical Stage | Stage Size: 145*140mm Travel: 76mm*52mm, Scale: 0.1mm,Two Slide Holder | Y | Y |
Condenser | Abbe N.A. 1.25(Iris Diaphragm) | Y | Y |
Illumination | 6V/20W Halogen Lamp | Y | Y |
6V/30W Halogen Lamp | O | O | |
LED Illumination Systems(W/O Rechargeable) | O | O | |
Filter | Blue(Built In) | Y | Y |
Image Systems |
| 3.2MP Pixel | 5 MP Pixel |
Note: "Y"In Table Is Standard outfits, "O" Is Optional Accessories.
Packing Size: 570mm*275mm*450mm Gross Weight: 8 kgs Net Weight: 7 kgs
