Gas Chromatograph/chromatography Price With Chromatography Column

FOB Price

US$ 3,500 - 7,500 / Piece

1 Piece(Min. Order)

Port shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Drawell		Place of Origin	Shanghai, China
Model Number	DW-GC1120

Product Description

Gas Chromatography
Picture / Specification
Model#		DW-GC1120
Sample Introduction System		sample injector and evaporation chamber
Column Oven	Temperature range	Ambient temperature +7℃ ~ 400℃ (in 1℃ increment)
	Temperature accuracy	± 0.02℃
	Cooling time	400℃ to 50℃ in 8-10 min at 25℃ ambient
	Programmed temperature setting	0.1℃~40℃/min (in 1℃ increment)
	Program ramps	7 ramps in total (10 ramps available with control workstation)
	Size (LWH)	284280241mm(inside)	340345281mm(outside)
Flame Ionization Detector (FID)	Detection limit	≤3×10-12g/s (C16)
	Best test result	≤3*10-12g/s (C16)
	Drift	≤6*10-13A/30min
	Noise	≤5×10-14A
	Linearity range	≥106
Thermal Conductivity Detector (TCD)	Sensitivity	≥5000mV, mL/mg (C16)
	Baseline noise	≤20µV
	Drift	≤60µV/h
	Linearity range	≥104
Flame Photometric Detector (FPD)	Detection limit	≤8×10-13g/s(P) ; ≤8×10-11g/s(S)
	Drift	≤2×10-11A/30min
	Baseline noise	≤5×10-12A
Nitrogen-Phosphorus Detector (NPD)	Detection limit	≤5×10-12g/s(N) (Azobenzene) ≤5×10-13g/s(P) (Malathion)
Features:
Control system: designed for monitoring and controlling the instrument via the computer. Column Compartment/oven with superior thermal performance, multistage (10 ramps) programmed temperature control function. (supported by “control system”) Advanced built-in data acquisition system , supporting real time instrument status monitoring, detection signal acquisition and PC control Column oven accommodates up to 3 chromatographic columns, and supports quick heat-up and rapid cool-down with automated back-door opening. Flexible sample introduction system: 3 sample injectors could be installed and operated simultaneously with independent temperature control. High sensibility and stability detector. 2 independent and analog signals output. M6 software, compatible with GLP/FDA-21 CFR Part11 requirements and regulations. (electronic records and signatures)
Gas chromatography and accessories:
Carrier Gas System + Sample Introduction System + Separation System + Temperature Control System + Detector Carrier Gas System: air source/ purification and desiccation device/ flow rate control device Sample Introduction System: sample injector Separation System: chromatographic column(packed column and capillary column) Temperature Control System (Column Oven): constant temperature and programmed temperature Detector: FID/ TCD/ FPD/ NPD
