Home > Products > Motor > Customizable High Speed Low Torque 12V 3000RPM Micro Brushed DC Electric Motor BMM362M3
Customizable High Speed Low Torque 12V 3000RPM Micro Brushed DC Electric Motor BMM362M3
US$ 34 - 61
/ Piece
2 Pieces(Min. Order)
- Shanghai Ningbo
- T/T Credit Card
You May Like
-
Dureable 76 Diameter 3200RPM High Speed 12V 24V dc Motor BMM76008W
-
7.5A 86RPM Customizable Solar Tracking Motor Medical Equipment Use Motor Low RPM Gear Planetary Reduction DC Motor BMM5092E
-
24V 100W Chinese OEM Low Power Planetary Reduction Motor Brushed Standard Gear Motor for Precision and Solar Tracking BMM5094E
-
24V Solar Track Motor High Torque Planetary Gearbox DC Gear Motor BMM12007M
-
Dureable 12V 24V 76 Diameter 3000RPM High Torque 1NM dc Motor BMM76009W
-
7.5A Low Torque Low Speed Reduction Multi-Functional Small DC Gear Motor Micro Brushed DC Motor BMM5095E
Product Details
| Brand Name | Mcmaster | Place of Origin | Jiangsu, China | |
| Model Number | BMM362M3 | Type | Micro Motor | |
| Certification | CCC, ROHS | Torque | 0.2N.M | |
| Usage | Boat, Car, Electric Bicycle, Fan, Home Appliance | Construction | Permanent Magnet | |
| Efficiency | IE 2 | Protect Feature | Totally Enclosed | |
| Continuous Current(A) | 9.5A | Speed(RPM) | 3000RPM | |
| Commutation | Brush |
Product Description
|
|
VOLTAGE (VDC) |
NO LOAD |
RATED LOAD |
TORQUE (Nm) |
Power (W) |
O.D. (mm) |
LENGTH (mm) |
||
|
CURRENT (A) |
SPEED (r/min) |
CURRENT (A) |
SPEED (r/min) |
||||||
|
BMM362M3-1 |
24 |
0.3 |
3600 |
1.5 |
3200 |
0.06 |
20 |
45 |
67 |
|
BMM362M3-2 |
24 |
0.3 |
4300 |
1.5 |
3700 |
0.05 |
19 |
45 |
67 |
|
BMM362M3-3 |
24 |
0.3 |
4300 |
1.5 |
3700 |
0.05 |
19 |
45 |
67 |
|
BMM362M3-4 |
24 |
0.3 |
3600 |
1.5 |
3200 |
0.06 |
20 |
45 |
67 |
|
BMM362M3-5 |
24 |
0.3 |
3600 |
1.5 |
3200 |
0.06 |
20 |
45 |
6 |
For more information, you can visit our website
