Home > Products > Motor > Customizable 24V Robot Motor DC Electric Motor High Torque Planetary Reduction Gear Electric Motor BMM505M2
Customizable 24V Robot Motor DC Electric Motor High Torque Planetary Reduction Gear Electric Motor BMM505M2
US$ 85 - 139
/ Piece
2 Pieces(Min. Order)
- Shanghai Ningbo
- T/T Credit Card
You May Like
-
Customizable Precision Equipment 24V High Torque Gear Reducer Motor BMM505M3
-
BMM362W Durable 12V Low Torque High Speed 0.2Nm 3000 RPM Customizable Small Brush DC Motor
-
24V High Torque Planetary Gearbox Brush DC Gear Motor BMM12010M
-
BMM3625E 12V 0.2Nm 3000 RPM Customizable Low Torque High Speed Durable Micro Electric Brush DC Motor
-
OEM Customizable Durable Low RPM High Torque Planetary Reduction Gear Motor BMM509W
-
OD 76MM 2000RPM High Speed 12V 24V Brushed Electric DC Pump Motor BMM76001M
Product Details
| Brand Name | Mcmaster | Place of Origin | Jiangsu, China | |
| Model Number | BMM505M2 | Type | Gear Motor | |
| Certification | CCC, ROHS | Torque | 6N.M | |
| Usage | Boat, Car, Electric Bicycle, Fan, Home Appliance | Construction | Permanent Magnet | |
| Efficiency | IE 2 | Protect Feature | Totally Enclosed | |
| Continuous Current(A) | 7.5A | Speed(RPM) | 170RPM | |
| Commutation | Brush |
Product Description
|
VOLTAGE (V) |
NO LOAD |
RATED LOAD |
Torque (N.m) |
RATIO |
STAGE |
Power (W) |
LENGTH (mm) |
|||
|
CURRENT (A) |
SPEED (r/min) |
CURRENT (A) |
SPEED (r/min) |
|||||||
|
BMM505M2 |
24 |
1.39 |
201 |
7.48 |
167 |
5.8 |
18 |
2 |
102 |
190 |
|
Voltage (VDC) |
No Load |
Rated Load |
Toque (N.m) |
EMF constant (V/rpm) |
torque constant (N.m/A) |
Length (mm) |
||
|
Current(A) |
Speed(r/min) |
Current(A) |
Speed(r/min) |
|||||
|
24 |
1.12 |
3614 |
7.48 |
3000 |
0.4 |
0.0065887 | 0.0629 | 115 |
