Home > Products > Solenoid Valve > 4-inch agricultural irrigation solenoid valve
4-inch agricultural irrigation solenoid valve
- 10000 Set / Sets per Month
- Ningbo or shanghai Port by sea or air.
- T/T Credit Card
You May Like
-
201BM 2" plastic solenoid valve electric remote control irrigation 2 inch agriculture landscaping female BSP flange DN250 AC DC
-
agriculture plastic irrigation solenoid valve DN40 150P 1.5 in. with flow control 1 1/2 INCH 24VAC DC LATCHING NC
-
irrigation solenoid valve 3/4 inch 075D landscaping sprinkler valve electric magnetic for rain brid CP075
-
Plastic irrigation solenoid electric magnetic valve 2 inch 200P Flow control on off
-
plastic irrigation solenoid valve 4in. water flow control on and off 400P with flange electric magnetic Latching female thread
-
plastic irrigation solenoid valve 4in. water flow control on and off 400P with flange electric magnetic Latching female thread
Product Details
Brand Name | zanchen | Place of Origin | Zhejiang, China | |
Model Number | 400PH | Material | Plastic | |
Application | General | Structure | Pilot | |
Pressure | Medium Pressure | Power | Solenoid | |
Port Size | 4" DN100 | Media | Water | |
Temperature of Media | Medium Temperature |
Product Description
Body constructed of durable glassfilled nylon for long life and reliable performance. Stainless steel studs molded into the body resist thread damage.
Slow closing to prevent water hammer and subsequent system damage.
Fabric-reinforced diaphragm for longer life.
Flow: 0,06 to 120.0 m3/h
Pressure: 1.4 to 13.8 bar (23° C)
Temperature: up to 66° C
Electrical specifications
Solenoid: 24 VAC - 50 Hz
Inrush current: 0.41 A (9.9 VA)
Holding current: 0.23 A (5.5 VA)
Ease of Service
One-piece solenoid with captured plunger and spring for easy servicing.
Prevents loss of parts during field service.
Flow control handle adjusts water flow as needed.
Manual internal bleed with 1/4-turn of the solenoid operates the valve without allowing water into the valve box. Allows pressure regulator adjustment without turning on the valve at the controller.
Manual external bleed permits flushing debris from the system.
Recommended for system start up and after repairs.
Solenoid with convenient handle.
Versatility
Globe configuration.
Wide operating pressure range. Low flow operating capability for a wide range of applications.
Accepts zanchen latching solenoids for use with zanchen battery powered controllers.
Important: do not exceed 10 bar operating pressure when using the latching solenoid.
