XPLE Insulated Power Cable 150mm2 LV
- qingdao
- T/T Credit Card
You May Like
Product Details
| Brand Name | shuangjia | Place of Origin | Henan, China | |
| Model Number | YJLV22 0.6/1kv 4X120 | Type | Medium Voltage | |
| Insulation Material | XLPE | |||
| Jacket | PVC | Conductor Material | Aluminum |
Product Description
XLPE insulation power cable 150mm2 LV
The Type and Main Application
Type Name Main Application
Cu Core, Al Core
No. Of Cores: 4
Rated voltage: 0.6/1kv
Norminal thickness of insulation: 1.2mm
Approx. Overall diameter: 46.2mm
Max cable weight: 2860kg/km
Nominal cross sectional area of conductor: 1.5~400mm2
Standard
The product is manufactured according to the standard of GB12706 or IEC, BS, DIN and ICEA upon request.
Applications
The product is suitable for use in power transmission and distribution lines with rated power frequency voltage 3.6/kV-26/35kV
Operating characteristics
1, Rated power-frequency voltage Uo/U: 3.6/kV-26/35kV
2, Max. Permissible continuous operating temperature of conductor: 90
3, Max. Short-circuit temperature of conductor shall not exceed 250. (5s maximum duration ).
4, The ambient temperature under installation should not below 0
5, The bending radius of a single-core cable should not less than 20 times of the cable diameter. The bending radius of a three-core cable should not less than 15 times of the cable diameter.
Voltage designation
The rated voltage of the cable for a given application shall be suitable for the operating conditions in the system in which the cable is used, and is expressed in the form of Uo/U (Um)KV. Where:
Uo-The rated power-frequency voltage between conductor and earth or metallic scieen, for which the cable designed;
U-The rated power-frequency voltage between conductors, for which the cable designed;
Um-The maximum value of the highest system voltagefor which the equipment may be used
Specification Size and Technical Data
Type | YJLV YJLV22 YJLV32 YJLV YJLV22 NH(ZR)-YJLV NH(ZR)-YJLV NH(ZR)-YJLV22 |
Voltage Grade | 8.7/10 KV |
Nominal Section(mm²) | 3x2.5+1x1.5, 3x4+1x2.5, 3x6+1x4, 3x10+1x6, 3x16+1x10, 3x25+1x16, 3x35+1x16, 3x50+1x25, 3x70+1x35, 3x95+1x50, 3x120+1x70, 3x150+1x70, 3x185+1x95 |
Our factory specializing in diverse cables and wires. If you have any need , pls inform us at all times.
