Driving Concrete Laser Screed RWJP14

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	ROADWAY	Place of Origin	China
Model Number	RWJP14	After-sales Service Provided	Engineers available to service machinery overseas
Weight	1200kg	Dimension(LWH)	2717 × 2760 × 2380mm
Voltage	NO	Condition	New
Power(W)	20HP / 3600rpm

VIDEO:/lnBjjKmloo-kqikKBljlmSRnikqrrnrlmppor-f258370889b94d4b8678e0d8e543a0b7

Technical Parameters

Engine		Screed system
Model	HONDA GX630 electric start	Screed head type	Swing type
Type	Gasoline engine,air-cooled, 4 stroke, OHV, double cylinder	Width	2500mm
Power	20HP / 3600rpm	Paving type	With auger
Fuel tank volume	40L	Auger force	hydraulic motor
Fuel consumption	313g / kWh	Exciting force	500N
Running system		Vibration frequency	50Hz
Drive	4 Hydraulic drive motor	Screed plate height	350mm
Running speed	0-35m / min	Operation mode
Laser control system		forward and reverse	Hand grip control, stepless speed walking
control method	Microcomputer laser scan	Steering	Hydraulic control
Control effect	Flat, slope or double slope (3D)	Cleaning system
Size and weight		Power	Hydraulic motor
Outline dimension	2717 × 2760 × 2380mm	Theoretical flow	20L / min
Weight	1200kg	Rated pressure	7MPa
