CWX-15N 1/2 DN15 Electric DC12V 24V Brass Actuated Ball Valve Manufacturers Without Manual Override
- T/T Credit Card
You May Like
-
DC9-24V Timing Valve Brass 2 or 3 Way Mini Water Ball Valve
-
CWX - 15N/Q Brass 2 Way Electric Water Quick Open and Close / Mini Electric Valve
-
2/3 Wires DN15 Dn20 Dn25 DN32 2way Control Electric Brass Plastic Ss304/316 Motorized Ball Valve
-
12V 24V Stainless Steel 2 Way Electric Motorized Ball Valve DN15 DN20 DN25
-
CWX-15N 5v 3.6v DN20 DN25 DN32 Brass SS304 SS316 Plastic Mini 2 Way Electric Motorized Water Ball Valve
-
2/3/4 Wires 2/3way Dn20 Control Electric Brass Plastic Ss316 Motorized Ball Valve
Product Details
| Place of Origin | China | Model Number | CWX-series | |
| Structure | Ball | |||
| Port Size | 1/4inch to 1inch DN8-DN25 | |||
| Temperature of Media | Medium Temperature |
Product Description
CWX-15N 1/2 DN15 electric DC12V 24V brass actuated ball valve manufacturers without manual override
1.Metal gearbox and POM gear design, low noise, perform reliably .
2.Long service life: more than 100000 circles.
3.Electric limit and machinery limit design, located accurately, avoid gear run continuously.
4.Mufti-angle assembling, easy to install.
5.Float ball structure, no leakage,especially suitable for heavy pollution conditions.
1.Heat energy meters, fire work, save water system.
2.Auto control system, industrial mini auto control equipment.
3.Water saving equipment, drinking water equipment.
4.Air-conditioning fan coin(HVAC).
| Product Model | Rated Voltage | Working current | Output torque | Open/close time | Size |
| CWX-15Q | DC3-6V DC12V AC/DC9-24V AC220V AC85-265V | Max100mA (CR04 except Max150mA) | Max1.5NM | <3s | DN8-DN20 |
| CWX-15N | Max2.0NM | <5s | DN8-DN32 | ||
| Working pressure | Power | Medium temperature | Control mode | IP Grade | Special function |
| Max1.0Mpa | <3W | 0-90℃ | CR01 CR02 CR02+ CR03 CR03A CR04 CR05 | IP65 | CR01 CR02 CR03 CR04(with singal feedback) |
Brass
| Connection | Sizes | d | H | L |
Both female thread
Full-port | DN8 | 8 | 46 | 31 | |
| DN15 | 15 | 57 | 38 | ||
| DN20 | 20 | 71 | 45 | ||
| DN25 | 23.5 | 72 | 49 | ||
Both female thread
Reduce-port | DN10 | 8 | 46 | 31 | |
| DN20 | 15 | 66 | 38 | ||
| DN25 | 20 | 72 | 47 | ||
| DN32 | 25 | 86 | 60 | ||
Vertical Three-way | DN15 | 12 | 63 | 49 | |
| DN20 | 15 | 66 | 53 | ||
| Female-male thread | DN15 | 15 | 63 | 38 | |
| DN20 | 15 | 66 | 38 | ||
| DN32 | 20 | 76 | 50 | ||
| Both male thread | DN15 | 15 | 68 | 38 | |
| SS304/316 | Both female thread | DN8 | 8 | 46 | 31 |
| DN10 | 8 | 46 | 30.5 | ||
| DN15 | 15 | 55 | 38 | ||
| DN20 | 15 | 63 | 39 | ||
| DN20 | 20 | 71 | 45 | ||
| DN25 | 20 | 75 | 47 | ||
| DN25 | 25 | 72 | 49 |

Tianjin Tianfei High-Tech Valve Co., Ltd. is a professional manufacturer of electric valve
and manual valve, is a founding company of Tianjin Valve industry.Tianfei has a professional R & D team,has won many letters of petent and the recognition of the Tianjin municipal government departments.“CWX”is our brand and our company has passed theISO9001,CE,RoHS,NSF61 certificate and so on,the products have exported to many countries and regionsworldwide.
Our company motto is novative, simplified, high-valued, As having accumulated rich experiences and resources during more than 10 years developing,
we are confident inproviding you satisfied products and service in the cooperation. Tianfei pays attention to the quality of the products,use “CWX” valve is your correct choice.


1. Are you manufacturer or trading company?
We are manufacturer, we had been produced electric valve for more than 10 years. So we have advantage in price. We also could do OEM.
2. What's the payment method?
T/T,Paypal,Western Union ect.
3.What's your Minimum Order Quantity (MOQ)?
Our MOQ is 1piece.
4. What about the delivery time?
The delievery time for producing 50-100 pieces of motorised valves is 30-40 days after order confirmed.Samples could be prepared in 7 working days.
5.Would you have a discount if l have a large order?
CWX-series
5% discount--- 50pieces
10% discount---100pieces
15% discount---500 pieces
6.Where is the factory located?
Tianjin city and welcome to visit our factory.
