High Speed Small Thinest Mini 4/6/8/12 Circuits Capsule Slip Ring
- 1000 Piece / Pieces per Month
- yantian
- T/T PayPal
You May Like
-
CCTV Monitoring System 360 Rotating mini Capsule slip rings with long use life
-
Signal UAV High Speed Ball Toy Rotary Electrical Capsule Slip Ring Rotating Connector
-
Capsule type HDSI HDMI video slip ring 1 channel HD video conductive ring for radar signal
-
Shenzhen 12 Circuits Lead Free Shadowless lamp Video Connector Capsule Slip Ring
-
SDI series IP54 Proteaction HD 1080P Video Capsule Slip Ring
-
Alloy Aluminum Capsule Slip Ring
Product Description
electrical slip ring Description
The JSR-CS Series miniature slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary part to a rotating part.
The JSR-CS Series unit is a standard, off-the-shelf unit that uses gold contacts at the rotary interface. Color-coded lead wires are used on both the stator and rotor for simplifying electrical connection.
A slip ring is an electromechanical device that allows the transmission of power and electrical signals from a stationary to a rotating structure.The JSR-CS Series, with 6 wires and compact 22.00mm body diameter, which we call our “mini”, is our newest design and smallest physical package.uses JARCH's fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates. JSR-CS Series is Compatible with data bus protocols,Transfers analog and digital signals.
Dimension:
CCTV Monitoring System 360° Rotating Long Life mini Capsule slip rings
Specification:
| Operating Speed | 0-250 rpm |
| Number of Circuits | 2 |
| Voltage | 240 VAC/DC |
| Current Rating | 5A per circuit |
| Temperature Range | -20°Cto +80°C |
| Contact Material | Gold to Gold |
| Lead Size | 28# silver plated copper |
| Lead Length | Standard 250 mm(9.843inch) |
| Dielectric Strength | ≥500 VAC @50Hz, between each circuit |
| Insulation Resistance | 100 MΩ @ 500 VDC |
| Electrical Noise | 1mΩMin |
Benefits:
· Smoother running.
· Higher design precision
· Lower electrical noise.
· Lower torque, lower contact resistance
· Rapid delivery
CCTV Monitoring System 360° Rotating Long Life mini Capsule slip rings
Applications:
CCTV Monitoring System.
Electrical test equipment.
Medical equipment.
Rotary table
Robotics
Laboratory equipment
Manufacturing and process control equipment
CCTV Monitoring System 360° Rotating Long Life mini Capsule slip rings
Electrical induction motor swivel Capsule slip ring
Installation Instructions
