valve retainer brass gas connector digital timer solenoid valve
- Ningbo
- T/T Credit Card
You May Like
-
pressure relief valve for solar water heater solenoid vacuum valve solenoid valve irrigate
-
metal seat ball valve steam pressure reducing valve 12v gas solenoid valve
-
round star solenoid valve beer valve electric actuator gate valve
-
mini plastic check valve flow control valve hydraulic flanged gate valve
-
motor operated valve price ductile iron globe valve bermad valve
-
pvc true union ball valve brass ball valve in yuhuan class 1500 high pressure ball valve
Product Details
Brand Name | GOGO | Place of Origin | Zhejiang, China | |
Model Number | MI-05 36 | Material | Brass | |
Structure | Control | Standard or Nonstandard | Standard | |
Pressure | Medium Pressure | Power | Solenoid | |
Port Size | 1/8" 1/4" 3/8" 1/2" | |||
Temperature of Media | Medium Temperature |
Product Description
valve retainer brass gas connector digital timer solenoid valve
1. Brass ;
2. Stainless steel .
Specification
Pattern: | Two-port two-position | |||
Principium: | direct acting type | |||
Control mode: | normally close | |||
Valve body: | brass | |||
Diaphragm material: | NBR: ≤80°C ,FKM≤150°C | |||
Working pressure: | 0~10bar | |||
Max pressure: | 10bar | |||
Voltage: | AC220V AC110V DC12V DC24V | |||
Medium: | Air ,water ,Liquid ,oil ect. | |||
Application: | Gas protection welder, various types of burners, test equipment small-flow air water control system |
3: We'll tell you the tracking number once your order has been sent.
Package
1:Inner packing: opp bag, then carton box for each product.
2:Outer packing: export standard carton, Foam outside protecting the goods against damage
Dimensions
(mm)
Orifice(mm) | A | B | C |
DN3 | 44 | 25 | 80 |
DN4 | 44 | 25 | 80 |
DN5 | 50 | 25 | 80 |
DN8 | 50 | 25 | 80 |
Materials of construction | |||
Parts in contact with the medium | |||
Valve of body | Brass | SS304 | |
Seals | NBR ,EPDM ,FKM | ||
Magnetic isolation pipe | SS304 | ||
Core | Stainless steel alloy | ||
Spring | SS304 | ||
The shading | Copper |
small brass and plastic non return valves solenoid gas valve
Material of Oil Seal : NBR , EPDM , VITON
Valve body made of Aging-proof Corrosion-Resistant Reinforced Nylon for the long life duration.
Voltage: DC12V,DC24V,AC24V,AC36V,AC110V,AC220V,AC380V
- Inner packing: opp bag, then carton box for each product
- Outer packing: export standard carton, Foam outside protecting the goods against damage
- Usually we ship your order by sea or by air...
- We do our best to ship your order within 1 week after receiving your payment
- We'll tell you the tracking number once your order has been sent
- We accept T/T Bank transfer, L/C, Western Union, Moneygram, Paypal
- We have more than 12 years experience in solenoid valves
- Excellent quality control is one of our main principles
- Various style for each products and completely series pneumatic products for you to choose from
- Sample order & small quantity order is ok
- We provide OEM service, accept customer label, develop the product with your drawings or samples
- Any question, will be replyed within 24 hours
Founded in July,2014, Ningbo Fenghua GO GO Automatic company is a high-tech enterprise with all vitality, potential and comprehensive strength. The company is located in the Zhejiang Ningbo Science &Technology zone, a unique place with beautiful scenery and gifts of nature.
Main products of our company : automatic parts, pneumatic solenoid valve, air water solenoid valve, hydraulic valves, gear piston or vane pumps, temperature controller, PLC, DCS parts, hardware stainless steel or brass or plastic parts , etc.
Since its foundation, the company keeps living up to the belief of :"honest selling, best quality, people-orientation and benefits to customers. " We are doing everything to offer our customers with best services and best products. We promise that we'll be responsible all the way to the end once our services begin.
Q: What is your main market?
A: Our main market is north America, especially USA.
Q: Are you products standard?
A: Our model is standard, if you have specific demand, pls tell us.
Q: Do you have interest to do our own design items?
A: Absolutely! We have big interest.
Q: How to make the order?
A: You can send us email or inquiry at alibaba directly. for samples order, you can go to our aliexpress shop and place the order.
