Home > Products > Crossed roller bearings > CRBF2012 ATUU crossed roller bearing 20x70x12mm for robots arm
CRBF2012 ATUU crossed roller bearing 20x70x12mm for robots arm
- 1000 Piece / Pieces per Month
- Shanghai
- T/T L/C PayPal Other
- 30 days
You May Like
-
CRBF2512 ATUU crossed roller bearing 25x80x12mm
-
CRBF3515 ATUU crossed roller bearing 35x95x15mm
-
RKS.23 0541 light series slewing bearing 434x648x56mm
-
RKS.23 0641 slewing bearing 534x748x56mm for circular scrapers
-
RKS.23 0841 slewing bearing 734x948x56mm slewing ring with flange
-
VLU200414 slewing bearing 304x518x56mm wholesale
Product Details
| Brand Name | RIGBRS | Place of Origin | China | |
| Model Number | CRBF2012 ATUU | Feature | Cross Roller | |
| Seals Type | NBR | Outside Diameter | 70, | |
| Bore Size | 20, | Gear Options | Nongeared |
Product Description
Model: CRBF2012ATUU
Inner ring: 20mm
Outer ring: 70mm
Width: 12mm
Weight: 0.29kg
Structure: crossed cylindrical roller bearing
Materials: GCr15 bearing steel
Precision grade: P5/P4
Lubrication type: Grease lubrication
Lubrication hole: Yes
Load direction: axial, radial and tilting moment.
1. CRBF2012 crossed roller bearing has solid one-piece inner and outer ring, provide stable running accuracy and torque, suited for applications which require high rotation accuracy of both inner and outer ring.
2. Besides, it can take combined loads, resistant to shock loads, and precision won't be affected by mounting errors.
3. Easy to arrange installation by bolts or screws.
Application: waist joints of robots, rotary table, radar, precision measuring instruments, etc.
Surface treatment: surface blackening, phosphate treatment, zinc-plating,etc. to protect bearings from rust or corrosion.
| CRBF series | Equivalent Model | d(mm) | D(mm) | B(mm) |
| CRBF 108 AT UU | / | 10 | 52 | 8 |
| CRBF 2012AT UU | RU42 | 20 | 70 | 12 |
| CRBF 2512 AT UU | / | 25 | 80 | 12 |
| CRBF 3515 AT UU | RU66 | 35 | 95 | 15 |
| CRBF 5515 AT UU | RU85 | 55 | 120 | 15 |
| CRBF 8022 A UU | RU124 | 80 | 165 | 22 |
| CRBF 8022 AD UU | RU124(G) | 80 | 165 | 22 |
| CRBF 8022 AT UU | RU124X | 80 | 165 | 22 |
