125KHz USB HITAGS Reader Writer, EM Series Card RFID Reader, ISO 11784/11785
- SHENZHEN
- T/T PayPal
- 5 days
You May Like
-
Inbuilt TTL MIFARE DESFire EV1/EV2/EV3 Reader Writer, ISO14443A/B, ISO15693
-
Dual Frequency LF & HF RFID Reader Writer, 125KHz& 134.2KHz and 13.56MHz, Smart Card Reader
-
MIFARE DESFire EV2 RFID Module, MIFARE card RFID Reader Module, ISO14443A/B, ISO15693
-
Inbuilt Antenna MIFARE DESFire EV2/EV3 RFID Module, 13.56MHz Reader Module
-
USB HID MIFARE Reader, RFID MIFARE DESFire NFC Desktop Reader, ISO14443A
-
RS232 Inbuilt Antenna MIFARE Reader Module, NFC RFID Reader Writer, ISO14443A
Product Details
| Brand Name | CHIKEK | Place of Origin | China | |
| Model Number | CHK101WU |
Product Description
Key Features:
Frequency available with 125KHz and 134.2KHz
Micro USB connector, Virtual USB port;
Compliant with ISO11784/11785 international standard, support FDX-B protocol
Available to Read/write HITAG series tag, including HITAG 1, HITAG S64/ 256/2048.
Support to read UID of EM4100/4200, TK4100 cards;
Available to format HITAG series card to FDX-B animal ear tags or ID card format;
Internal antenna, reading distance up to 50~70mm;
Internal LED and BUZ for working status indication
Technical Parameters:
Electrical Specification | |
Power supply | DC 5V from USB port |
Power consumption | Max current:<50mA, Standby current: <1 mA |
Operation frequency | 125KHz, 134.2KHz |
Baudrate | 9600~115200 bit/s ( default 9600bps) |
Interface | micro USB |
Antenna | Internal |
Reading range | 50- 70mm (depends on tag and antenna size) |
Mechanical Specifications | |
Dimension | 110mmx70mmx18mm(LxWxH) |
Weight | 50g |
Material | ABS, Black gloss surface |
Model | CHK101WU |
Environmental Conditions | |
Operation temperature | -20°C～ +80°C |
Storage temperature | -40°C～ +85°C |
Humidity | Relative humidity 5%～95% |
Supported Standard/ Tags | |
EM4100,EM4200, TK4100 | |
ISO/IEC 11784/11785 | HITAG 1, HITAG S 64, HITAG S 256, HITAG S 2048 |
SDK information | |
Demo software | Windows, C# program language |
Files | Comprotocol document API document User Manual Demo.exe |
