EUS900 EUI EUP/HEUI/ Common Rail Injector Test Bench EUS9000

                      Common Rail Pump And Injector Test Bench EUS9000 (HEUI+EUI EUP)

Automatically test C7/C9/C-9,C3126/3408,Ford Power Stroke  6.0  and so on middle pressure common rail product.

Automatically test the injector seal, actuation point, pilot injection, medium speed, maximum load, the maximum test pressure is 2400 bar

Automatically test Bosch, Carter, CUMMINS, DDC, Delphi, Mercedes-Benz, Volvo, EUI/EUP and dual-valve E3,CUMMINS ISX and other special products

Automatically test oil return function of HEUI.

Support Fuel injector response time(BIP)function, can judge the EUI/EUP performance quickly and accurately.

 · Technical parameter

1. Rated output power: 7.5KW ,11KW,15KW,18.5KW (on request)

2. Electronic power: 3PHASE 380V 50HZ OR 3PHASE 220V 60HZ

3. Motor speed: 0-4000RPM

4. Pressure adjustment: 0-2500bar

5. Fuel temperature: 40 ±2℃

6.Flow testing range:0-600ml/1000times

7.Flow measurement accuracy:0.1ml

8. Filter accuracy: less than 5um

9.Cooling system: fan or forced cooling

10. Fuel tank capacity: 60L

11.. Size: 1900MM * 900MM * 1500MM

9. Weight: 800kg

10. With 19-inch display

11. Adopt interference-free Logitech mouse

1, Diesel engine parts (nozzle, plunger, delivery valve, head Rotor, injector, fuel pump and other accessories)

2, Injection pump test bench

3, Auto tools

4, Auto parts

5, Special vehicles

6, Turbocharger.......

Production process using advanced computer control and digital display systems, production technology, strong technical force . High quality, high technical performance, with micro-controller and digital functions. Products are sold  more than 100 countries and regions of all world .
