Car Spray Booth

Outside Dimension

7000×5400×3450mm(L×W×H)

Main Door(W×H)

3 folds door , 3000×2600mm ,it is bending steel without cover frame.

This type is very strong and beautiful . Also equipped with Handle & Lock.

Personal Door

1fold ,800×2000mm(W×H). Equipped with Handle & Anti-Explosion Lock .

Wall Panels

-High quality double construction insulation EPS panel, thickness: 50mm.

-Galvanized steel roof panel .

Basement and Floor

- Galvanized steel assemble,Full metal foundation, height is 280mm .

- Five rows flat steel Grilles (galvanized)

- 3 pieces of Ramps, each size 970×2000mm (W×L),diamond plate construction.

With 2pieces inclined ramps.

Lighting System

-LED Ceiling lights:10 units×4pieces =40pieces ×16W

-LED Side lights: 10units × 4 pieces =40pieces ×16W

Generator

Setting Type

-Side upper intake air, quadrate steel frame, coated steel ,inside rock-wool insulation.

-Electric damper actuates from the spraying to baking cycle.

Inlet Fan

1×7.5KW YDW double-intake centrifugal fans, total air capacity: 18000m3/h.

Exhaust Fan

1×7.5KW YDW double-intake centrifugal fans, total air capacity:18000m3/h.

Heating System

-1set : RIELLO RG5S diesel burner, heating productivity: 260000 Kcal/h,

-Adopt high efficient heat-resistant stainless steel as cycling heat exchanger.

4-6minutes (from20 to 60o C) under baking status, max baking temperature is 80° C.

Filter System

-The primary filter can capture granules larger than 10μm , filtering rate > 83%.

-Ceiling filter can capture granules bigger than 4μm, filtering rate> 98%.

-Floor filter( fiberglass paint-stop filter ),filtering rate > 70%.

-Activated carbon filter or granules put in cabinet.

Control System

Lighting switch, spraying , heat spraying , baking , temperature controller,

time setting, emergency stop , failure indicator, hour meter, thermostat .

Total Power

17KW (380V/ 220V ,50HZ/ 60HZ ,3 Phase )
