High Carbon Steel Wire Woven Wire Mesh for Vibrating
Negotiable
/ Piece
10 Pieces(Min. Order)
You May Like
-
High Carbon Steel Crimped Woven Wire Mesh / Vibrating Screen Mesh
-
Crimped Wire Mesh Stainless Steel Weave Wire Mesh
-
High-Carbon Steel The Flat Panel Lock Crimped Weave Wire Mesh
-
Crimped Wire Mesh for Roast, Barbecue Grill Wire Netting
-
Used in Mining Aggregate Granite Steel Wire Mesh Screen
-
High Carbon Steel Vibrating Screen Mesh / Crimped Wire Mesh for Mining
Product Description
High Carbon Steel Wire Woven Screen for Vibrating(vibrating screen factory)
1>Material:The Product is made by low carbon iron wire, galvanized steel wire or stainless steel wire.
2>Mesh: 3x3mesh to 60x60mesh,
3>Feature: It has fine features of neat & precise, sturdy structure, durable& strongly rust-resistant and fine anti-corrosiveness. It's widely used in industry, agriculture, building, house fencing and so on.
4>Packaging: Wrapped with moister-proof paper, Then covered with Hessian cloth
5>General Use: Screening in mine, coal factory, construction and other industries.used as window screening, safety guards in machinery enclosures, also used in filtering liquid and gas, sieving grain.
| S/No | Description | Size | Thickness |
| 1 | Screen Mesh. Customized size | 0.5mm | 0.3mm |
| 2 | 1.0mm | 0.75mm | |
| 3 | 1.5mm | 1mm | |
| 4 | 2.0mm | 1.5mm | |
| 5 | 3.0mm | 2mm | |
| 6 | 4.0mm | 2.5mm | |
| 7 | 5.0mm | 3mm | |
| 8 | 6.0mm | 3mm | |
| 9 | 7.00mm | 3mm | |
| 10 | 8.0mm | 3mm | |
| 11 | 9.0mm | 3.5mm | |
| 12 | 9.5mm | 3.5mm | |
| 13 | 10.mm | 4mm | |
| 14 | 11.0mm | 4mm | |
| 15 | 12.0mm | 4mm | |
| 16 | 12.5mm | 4mm | |
| 17 | 13.0mm | 4mm | |
| 18 | 14.0mm | 4mm | |
| 19 | 15.0mm | 4mm | |
| 20 | 16.mm | 4mm | |
| 21 | 17.mm | 4.5mm | |
| 22 | 18.mm | 5mm | |
| 23 | 19.mm | 5mm | |
| 24 | 20.0mm | 6mm | |
| 25 | 21.0mm | 6mm | |
| 26 | 22.0mm | 6mm | |
| 27 | 23.0mm | 6mm | |
| 28 | 24.0mm | 6mm | |
| 29 | 25.0mm | 6mm | |
| 30 | 26.0mm | 6mm | |
| 31 | 30.0mm | 6.5mm | |
| 32 | 32.0mm | 7mm | |
| 33 | 35.0mm | 7mm | |
| 34 | 38.0mm | 8mm | |
| 35 | 40.0mm | 8mm | |
| 36 | 45.0mm | 8mm | |
| 37 | 50.0mm | 8mm | |
| 38 | 55.0mm | 8mm | |
| 39 | 60.0mm | 8.5mm | |
| 40 | 65.0mm | 8.5mm | |
| 41 | 75.0mm | 9 mm | |
| 42 | 80.0mm | 9 mm | |
| 43 | 90.0mm | 9mm | |
| 44 | 100.0mm | 10MM |
| mesh | wire diameter (mm) | opening (mm) | mesh | wire diameter (mm) | opening |
| 3x3 | 1.60 | 6.87 | 20x20 | 0.27 | 1.00 |
| 4x4 | 1.20 | 5.15 | 22x22 | 0.25 | 0.90 |
| 5x5 | 0.95 | 4.13 | 24x24 | 0.23 | 0.83 |
| 6x6 | 0.80 | 3.43 | 26x26 | 0.20 | 0.78 |
| 8x8 | 0.60 | 2.57 | 28x28 | 0.18 | 0.73 |
| 10x10 | 0.50 | 2.04 | 30x30 | 0.15 | 0.70 |
| 12x12 | 0.50 | 1.61 | 35x35 | 0.14 | 0.59 |
| 14x14 | 0.40 | 1.41 | 40x40 | 0.14 | 0.50 |
| 16x16 | 0.35 | 1.24 | 50x50 | 0.12 | 0.39 |
| 18x18 | 0.30 | 1.11 | 60x60 | 0.12 | 0.30 |
