Double Head Cutting Saw Saw Cutting of Aluminum and Price

double head cutting saw saw cutting of aluminum and price

Product Application

- Applying to sawing sorts of aluminum profiles for doors/windows and curtain walls by cutting at angles 22.5º, 45º and       90º.

- High quality servo motors are adopted. LCD touching display screen for operating control, through which the cutting

  lengths and angles are inputted. The automatic positioning for profile's length is available.

- Saw-straight-outgoing mode, connected parallelly with hydro-pneumatic control system, so as to ensure the feeding

  stability of the saw blades at stepless speed.

- The two sets of clamping cylinders clamp the profiles from two different directions horizontally and vertically, that

  makes the clamps more reliable.

- Hard alloy blade, automatic cooling spray device.
- Attached holding rack makes clamping easier.
- Automatic feeding and cutting.

Main Specification

1) Cutting length: 370mm - 4600mm
2) Profiles adaptable: 140(145)×270 (260)mm (width x height)
3) Blade size: Ф500 x 4 x 30
4) Power of main motors: 2.2kw x 2
5) Rotational speed of spindle: 2800 rpm
6) Pneumatic working pressure: 0.5 – 0.8 MPa
7) Air consumption: 0.2 cubic m/min.
8) Dimensions: 6000 x 1750 x 1700mm
9) Weight: 1500 kg

Cutting Precision
1) Repetition on length: ± 0.1mm
2) Repetition on angle: ± 5'
3) Verticality of cutting surface: 0.1mm (100x100mm section)
4) Planeness of cutting surface: 0.1mm (100x100mm section)
5) Roughness of cutting surface: Ra12.5 µm

45° CUTTING

                   90° CUTTING

TWO SETS OF

CYLINDERS TO CLAMP

PROFILES

          PERFECT CUTTING

Q: If I make Aluminum window and door, how many basic machines do i need?
A: Double head cutting saw ,Lock hole copy milling machine,End milling machine,
     Automatic Corner connector automatic cutting saw,Single head Corner Crimping machine.

Q: How can I get the best machine for our business?
A: Just let us know your cutting material, size, thickness, and working area needed.
     we will suggest the most suitable machine and professional solution.

Q: This is my first time using this kind of machine, is it easy to operate?
A: Of course the machine is easy to operare.
    We will send you the English version user manual and install video which shows how to
    assamble and use the machine clearly, almost all the customers can operate the machine
    easily.
    Don't worry about this. FEIDA will always be here to help!

Q: If the machine has problem in my place, how could I do?
A: Usually there won't be any problem under "normal use" as per the user manual.
    But in case you have any problem, our professional after-service team will provide you any
    support you need any time!
B: We can send you free components to you if your machines are in guarantee time.
C: We can send our engineers to repair your machines.

Q: This machine is not suitable for me, do you have more models available?
A: Sure, in order to meet different customers' different requirments, we reserched many other
    different machines.

Q: When can we arrange shipment?
A: We usually arrange shipment in 15 days after getting deposit, but customized machines should be
     more than 25 days.

Q: What services can provide in your company?
A: Two years guarantee
B: Free adjustment
C: Free training to operation and maintenance workers.
D: Free industrial information
E: Free investment analysis for windows, doors and curtain wall project.
F: Free layout design for windows,doors and curtain wall production lines.
G: Provide follow-up service, regular maintenance and lifetime service for our machines sold.
H: Provide technical support including pressure design and caculation for window and curtain
     wall companies.
I: Provide quick supply of spare parts for window and curtain wall companies.
