Corner Connector Aluminum Cutting Machine Price in Pakistan for Aluminium Window
- Xingang Port
- T/T Credit Card
You May Like
-
High Precision Automatic Used Machine for Cutting Aluminum Corner of Window and Door
-
Small End Milling Aluminium Windows Making Machine for Mullion Aluminum Window
-
Small End Milling Automatic Door Making Machine for Mullion Aluminum Window
-
Aluminum Window End Milling Door Closer Making Machine
-
High Precision Automatic Hydraulic Press Cutting Machine for Aluminum Corner of Window and Door
-
High Precision Automatic Digital Die Cutting Machine for Aluminum Corner of Window and Door
Product Details
| Brand Name | FEIDA | Model Number | JMJ-DW450 |
Product Description
Corner Connector aluminum cutting machine price in pakistan for Aluminium window
Product Application aluminum cutting machine price in pakistan
--Good at automatically cutting corner profiles, including thick-wall corner profiles.
--With automatic collecting tank for spare parts.
--With a trough for collecting cutting scraps and used coolant.
--Cooling spray system
--Safety cover for protecting operators from injury
--Automatic stop when processing finishes
Main Specification aluminum cutting machine price in pakistan
1) Max. length of profile: 300 mm
2) Mini. length of profile: 3 mm
3) Max. travel of sawing head: 90 mm
4) Blade diameter: Φ 450 mm
5) Blade aperture: Φ 30mm
6) Effective cutting length: 110 mm
7) Height of working stand: 1150 mm
8) Pneumatic working pressure: 0.5-0.8 MPa
9) Air consumption: 0.2 cubic m/min.
10) Blade feeding speed: 1-5 m/min.
11) Power of main motor: 3 kw
12) Rotational speed of spindle: 2800 rpm
13) Dimensions: 1150x2250x1450 mm
14) Weight: 500 kg
Cutting Precision aluminum cutting machine price in pakistan
1) Repetition on length: ± 0.1 mm
2) Repetition on angle: ± 5’
3) Verticality of cutting: 0.1 mm (100x100mm section)
4) Planeness of cutting surface: 0.1 mm (100x100mm section)
5) Roughness of cutting surface: Ra 12.5 µm
| Size | 2250(L) × 1450 (W) × 1150(H) |
| Weight | 500 KGS |
| Packing details | Aluminum foil vacuumed /aluminum cutting machine price in pakistan |
