JT02 equipment for window making insulating glass window aluminium spacer Butyl rubber coating thermal break aluminium machine
- Qingdao Port
- T/T Credit Card
You May Like
-
RYB-1600 hollow glass insulating glass double glass heat press window equipment
-
RYB-1600 hollow glass insulating glass double glass heat press thermal break machine
-
XZT-03 Automatic rotating Insulating glass sealing table aluminium window equipment miter door machine
-
DKMT-CNC Vertical insulating glass sealing glue production line thermal break aluminium window machine upvc machinery
-
YTJ-1600 insulating glass cleaning and hot pressing window machine upvc machinery
-
XZT-03 Automatic rotating Insulating glass sealing table aluminium window equipment glass rotate table
Product Details
| Brand Name | Hisena |
Product Description
JT02 Butyl rubber coating machine
For aluminum spacer butyl coating.
An important equipment for insulating glass production line.
Display butyl quantity automatically on screen.
Butyl coating averagely, Alarm when butyl is used up.
Adjust temperature and pressure automatically.
The machine can be turned on and off according to setup automatically.
Adopt imported gas-liquid pressurization system to make sure pressure is stable.
It’s also available for arc aluminum spacer.
Main Technique Parameter:
Power supply | 380V 50Hz |
Input power | 2.59kw |
Transmit speed | 0-15m/min |
Rubber tank | Φ 190mm |
Temperature | 140-160°C |
Squeeze pressure | 12-16Mpa |
Adjustable range of head | 3-30mm |
Air consumption | 50L/min |
Overall dimension | 3000x680x1080mm |
Weight | 850kg |
We can provide trainings to your workers .
IF the machine failure,we can send you the accessery by mail for free in the term of service or we can send our engineers .
We will follow the requirements of customers to arrange the packing and shipping .
HAIJINNA company is very expacted to do business with anyone who needs our products.
If you have any question about our products , contact us .
Contact person : Mr Ray Meng
Mobile:0086-18853160312
