Circular HSS Saw Blade Sharpening Machine for Cutting Disc

FOB Price

US$ 1,200 - 1,500 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Circular HSS Saw Blade Sharpening Machine for Cutting Disc GS-450(SG-1)

Product Description

Machine Main Features:

The clamp mould and knife wheel are designed finished to guarantee the central line of workpiece and knife wheel is exact. Thus, the outer angle, inner angle and pipe end machining may be finished evenly at one time.
It makes use of the change of belt wheel to shift different rotate speeds, so the life of blade may be as long s possible according to different metal materials.
The double-step feeding system saves working time. And the speed is slow for regulating easily.

Technique Parameter:

Model	GS-450(SG-1)
Saw blade diameter (mm)	50-450
Pitch range(mm)	max.25
Tooth depth(mm)	max.8
Range of cutting angle(degree)	0-30
Feeding speed(teeth/min)	45-180
Thickness of saw blade(mm)	max.8
Grinding wheel diameter(mm)	70-150
Wheel speed(rotation)	4,500
Transmission motor(hp)	1/2
Wheel motor(Hp)	3/4
Net weight(kg)	130
Machine Size(LWH)(mm)	8008001410
