Home > Products > PVC POWER CABLES > copper conductor PVC insulation and galvanized steel wire armour cables
copper conductor PVC insulation and galvanized steel wire armour cables
- Tianjin Qingdao or other main port
- T/T Credit Card
You May Like
-
LV xlpe insulation swa armoured copper armoured cable 4 core 25mm
-
low voltage CU/XLPE/SWA/PVC 4 core armoured 120mm2 elektrik cables
-
0.6/1kv 4cores 35mm PVC cable/copper power cable
-
Cable manufacture 4 core armoured 600v 1000v pvc power cable
-
China supplier low voltage copper cable nyy 4x16 with CE certificate
-
OEM service 600/1000V 4 core PVC insulated steel tape armoured power cable with high popularity in market by Chinese manufacture
Product Details
| Brand Name | RNEDA | Place of Origin | Hebei, China | |
| Model Number | VV32 | Type | Low Voltage | |
| Application | Underground | Insulation Material | PVC | |
| Jacket | PVC |
Product Description
copper conductor PVC insulation and galvanized steel wire armour cables
cable structure:
1.The conductor can be copper or aluminium; strands, solid, flexible.
2.The insualtion is PVC.
3.The Jacket/Sheath is PVC.
4.Armored or without armored: armoured material: Can be steel tape(sta) or steel wire(swa) or others as your request!
5.The recommended nominal cross section is from 1.5 sq mm to 630 sqmm.
6.The core number can be single or multi.
7.The Voltage is 0.6/1kV.
8.The long-time working temperature of cable should not be higher than 70 celsius.
9.When core is in short-circuit(max 5s) the temperature should not be exceed 160 celsius.
10.While installation the ambient temperature should not be lower than 0 celsius.
cable specification:
| Type | Discription | Rated Voltage (KV) | Number of cores | Nominal Cross-sectional Area (mm2) | |
| Cu | Al | ||||
| NYY /NAYY VV/YJV | VV/YJV: Copper conductor PVC/XLPE insulated and PVC sheathed powercables. VLV/YJLV: Aluminium conductor PVC insulated and PVC sheathed power cables. | 0.6/1KV | 1 | 1.5~1200 | 2.5~1200 |
| 2 | 1.5~300 | 2.5~300 | |||
| 3 | 1.5~300 | 2.5~300 | |||
| 4 | 1.5~300 | 2.5~300 | |||
| 5 | 1.5~300 | 2.5~300 | |||
| 3+1 | 1.5~300 | 2.5~300 | |||
| 3+2 | 1.5~300 | 2.5~300 | |||
| 4+1 | 1.5~300 | 2.5~300 | |||
| VV22 / YJV22 VLV22 / YJLV22 | VV 22 /YJV 22 : Copper conductor PVC insulated and PVC sheathed steel tap armoured power cables. VV 22 /YJV 22 : Aluminium conductor PVC insulated and PVC sheathed steel tap armoured power cables. | 0.6/1KV | 1 | 10~500 | 10~500 |
| 2 | 1.5~300 | 2.5~300 | |||
| 3 | 1.5~300 | 2.5~300 | |||
| 4 | 1.5~300 | 2.5~300 | |||
| 5 | 1.5~300 | 2.5~300 | |||
| 3+1 | 1.5~300 | 2.5~300 | |||
| 3+2 | 1.5~300 | 2.5~300 | |||
| 4+1 | 1.5~300 | 2.5~300 | |||
| VV32 / YJV32 VLV32 / YJLV32 | VV 32 /YJV 32 : Copper conductor PVC insulated and PVC sheathed steel wire armoured power cables. VLV 32 /YJV 32 : Aluminium conductor PVC insulated and PVC sheathed steel wire armoured power cables. | 0.6/1KV | 1 | 50~500 | 50~500 |
| 2 | 35~300 | 50~185 | |||
| 3 | 25~300 | 35~300 | |||
| 4 | 25~300 | 35~300 | |||
| 5 | 25~240 | 35~240 | |||
| 3+1 | 25~300 | 35~300 | |||
| 3+2 | 25~300 | 35~300 | |||
| 4+1 | 25~240 | 35~240 | |||









Established in 1993, Hebei Huatong Wires and Cables Group Co., Ltd covers an area more than 220,000 square meters, owning more than 420 sets manufacturing equipment and more than 250 sets of testing equipment or apparatus. Our annual production capacity is 3 billion Chinese Yuan. Now there are more than 800 employers in our company, among which more than 150 are technicians. With the continuous efforts from all the employers, Hebei Huatong Wires and Cables Group Co., Ltd has realized great development to become a modern enterprise and one of the comprehensive, largescale enterprises in domestic wire and cable industry. Our products are widely used in the field of electric power, coal, metallurgy, petrochemical industry, railway, national defense, construction, aviation and other national key projects. Our products have extensive influence and good reputation in both domestic and worldwide market, such as the United States, Holland, Italy, Russia, Britain, Australia, New Zealand, Ethiopia, Ghana, Algeria,Congo, Middle East and Southeast Asia and so on.
We have got the certificate of UL,CE,KEMA,TUV,Lloyd and “National Industrial Production License”, “Certificate of Recommended Enterprises and Products for National Grid”, “Adopting International Standard Certificate”, and “High-Tech Enterprise Certificate”, “Certificate of High Quality Products”, “Certificate of Scientific and Technological Achievements”, “Qualified Supplier Certificate”, “China Classification Society Certificate of Works Approval”, “Det Norske Veritas Type Approval Certificate”, “Railway Product Certificate”, “Safety Certificate of Approval for Mining Products”, “National Mandatory Product Certification”, “Certificate for China Compulsary Products Certification” and “Practical New-Type Patent Certificate”.
(1).When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please
call us or tell us in your e-mail so that we will regard your inquiry priority.
(2).How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight
charge should be paid.
(3).How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7
days. The samples will be sent to you via express and arrive in 3~5 days. You can use your own express account orprepay us if you do not have an account.
(4).What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is
delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months
before the date you would like to get the products at your country.
