Industrial Concrete Mixer Dry Mix Concrete Electric Concrete Mixer
- 100 Set / Sets per Month
- Shanghai/Qingdao/Tianjin
- T/T Credit Card
You May Like
Product Details
| Brand Name | Keming | Place of Origin | Henan, China | |
| Model Number | JS750 Concrete Mixer | After-sales Service Provided | Engineers available to service machinery overseas | |
| Condition | New | Outline Dimension | 4951*3650*6225 mm | |
| Discharge Way | Semi-automatic | Working Cycle Period | 120s | |
| Water Supply Mode | Automatic | Speed of Mixing Drum | 31r/min | |
| Motor Power | 7.5 Kw |
Product Description
JS750 Concrete Mixer
Industrial Concrete Mixer Dry Mix Concrete Electric Concrete Mixer
Industrial Concrete Mixer Dry Mix Concrete Electric Concrete Mixer
Introduction:
1. JS series concrete mixer is compulsory double-shafts concrete mixer,.
2. It is composed of feeding system, discharging system, water supply system and electrical system.
Industrial Concrete Mixer Dry Mix Concrete Electric Concrete Mixer
Features:
1.Mixing drums adopts high manganese steel liner and mixing blades, which are durable and easy to replace.
2.Concrete mixer has reasonable design, compact structure, easy operation.
3.Reliable working performance, good mixing quality, high productivity.
4.Long life of wearing parts, lower energy consumption, lower working noise.
Industrial Concrete Mixer Dry Mix Concrete Electric Concrete Mixer
Application:
1.JS series concrete mixer is mainly used to mix commodity concrete, such as hard concrete, plastic concrete, fluid concrete, lightweight aggregate, various mortars, etc.
2.Concrete mixer can not only work independently, but also can be equipped with batching machine to work as a concrete batching plant.
3.Concrete mixer is widely applied to various large and medium prefabricated factories and construction sites, roads, bridges, airports, tunnels and other projects.
Industrial Concrete Mixer Dry Mix Concrete Electric Concrete Mixer
Technical Parameters:
Model | JS500 | JS750 | JS1000 | JS1500 | |
Discharging volume (L) | 500 | 750 | 1000 | 1500 | |
Charging volume (L) | 800 | 1200 | 1600 | 2400 | |
Productivity (m3/h) | ≥25 | ≥37.5 | ≥50 | ≥75 | |
Max aggregate size (mm) | 80/60 | 80/60 | 80/60 | 80/60 | |
Mixing blade
| Speed (r/min) | 31 | 31 | 25.5 | 25.5 |
Quantity | 2*7 | 2*7 | 2*8 | 2*10 | |
Mixing motor
| Model | Y180M-4 | Y200L-4 | Y225S-4 | Y225M-4 |
Power(kw) | 18.5 | 30 | 37 | 45 | |
Hoist motor
| Model | YEZ132S-4 | YEZ132M-4 | YEZ10S-4 | YEZ180L-4 |
Power (kw) | 5.5 | 7.5 | 11 | 18.5 | |
Water pump motor
| Model | 50DWB20-8A | 65DWB35-5 | KQW65-100I | KQW65-100I |
Power (kw) | 1.1 | 1.1 | 3 | 3 | |
Hopper lifting speed (m/min) | 18 | 18 | 21.9 | 23 | |
Dimensions (mm) | Transport state | 3050*2300*2680 | 3650*2600*2890 | 4640*2250*2250 | 5080*2250*2440 |
Work state | 4461*3050*5225 | 4951*3650*6225 | 8765*3436*9540 | 9645*3436*9700 | |
Weight (kg) | 4000 | 5500 | 8700 | 11130 | |
Discharge height (m) | 1.5 | 1.5 | 2.7/3.8 | 3.8 | |
Industrial Concrete Mixer Dry Mix Concrete Electric Concrete Mixer
Industrial Concrete Mixer Dry Mix Concrete Electric Concrete Mixer
Henan Coal Research Institute Co., Ltd. was established in March 1979. In 1999, it was ranked among the first batch of 242 coal research institutes, and implemented localized management by Henan Province. In 2006, it was transformed successfully into a scientific and technological enterprise, and renamed officially as Henan Coal Research Institute Co., Ltd.
Achievements: As one of the standard setting unit of national shotcrete equipment industry, the company has obtained more than 170 research and development achievements, more than 110 technical consulting services, 82 technology awards and15 national invention patents and utility model patents.
Application: mining well project, hydropower engineering, highway (railway) tunnel, subway engineering, bridge and slope maintenance, air-raid shelter construction, municipal construction, environmental greening project, blast-furnace refractories spraying, etc.
Main Products: wet/dry shotcrete machine, concrete/shotcrete pump, grouting pump, mortar pump,slurry pump,hose pump, concrete mixer truck, concrete foaming machine, plastering machine etc.
Industrial Concrete Mixer Dry Mix Concrete Electric Concrete Mixer
1. Q: Which model should we choose?
A: We have many models for your choice. Before suitable model is recommended, please tell us the application, materials, output and pressure you want.
2. Q: Can we have customized model?
A: Yes. We can make the customized machine according to your actual requirements.
3. Q: Do I need to know technical skills to operate this machine?
A: No. This machine has no professional requirements for the operator. However, we provide technical instruction for your backup.
4.Q: What should we do if there are some problems with the machine?
A: You can refers to the Operate Instruction or contact us for online instruction. Also, our engineers are available to service overseas.
5.Q: What is the lead time?
A: 1 week for sample model, 2~3 weeks for customized model. It depends for mass production.
6.Q: How about the package?
A: We have fumigation-free wooden case to protect the machine from damage during the long-distance delivery.
7.Q :How should I pay for you if I place this order?
A: Generally, TT, 30% deposit 70% before shipment.
