Automatic horizontal pillow type chocolate packing machine

KD-260A Automatic reverse film packaging machine

Scope of application

This machine is suitable for the packing of product clump(e.g.betel nut,olive),packages of instant soup granule,solid bulk material,and other unequal like products like tiny electronic elements.

Featrues:

Compact structure,stable function and simple operation.

Double frequecy converter controller,length of package will cut immediately once setting,adjustment needless,saving time and film.

It adopts imported electric appliance,touch manmachine interface,convenient parameter setting.

Self-cheching function, trouble can be read easily.

High sensor photoelectric color chart tracking, make the cutting position more correctly.

Dependant temperature PID controlling suitable for various materials of packagingmenbrane.Position stop function, no adhesive and no waste of membrane.

Clean rotation system, more reliableoperation and more convenient maintenance.

All the controlling operates by the software,convenience for function ad-justment and technical up grading.

Main Technical Data:

Max.film width                                     260mm

Max packaging capacity(according to its material to fix)     50-120p/min

Suitable film thickness                               0.03-0.06mm

Length of bags                                      60-200mm

Packaging with                                     25-100mm

Packaging height                                    ≤35mm

Total power                                         2.7Kw 220V

Overall dimensions(L x W x H)                         2200 x900x1500mm

Weight                                             680kg
