Product Details
| Brand Name | WANTUO | Place of Origin | Henan, China | |
| Model Number | DST-32 | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | One Year | Weight | 320kg, 320kg | |
| Dimension(L*W*H) | 1200*800*900mm | Voltage | 220V/380V, 220V/380v | |
| Certification | CE ISO | Condition | New | |
| Power(W) | 15kw |
Product Description
Ice cream cone wafer making machine for sale / commercial ice cream cone making machine / waffle maker machine
Product introduction
The utility model relates to an ice cream crisp egg support machine, which uses flour as the raw material for production, and has the advantages of beautiful appearance and can be eaten.
The company's egg tray machine and a series of products, mold the same varieties can be mutually replaced, and can be a machine to match a variety of cone shape of the mold configuration, for exchange, to produce different shapes of the egg tray function.
Features of waffle maker machine
1, The same kind of mould can exchange and one machine can match many kinds of mould to exchange.
2,Designing and making different kind of cone according to specifications, capacity, color and shapes as customer offer
3.We can design your favorable cone shape according to your sample,your logo carving on the cone mold is possible.
4.Easy to operate and clean, one staff is enough.
Working process of waffle maker machine
1 flat machine on the horizontal table, not tilt.
2 connect the power, set the upper and lower die temperature, and then wait for the temperature rise.
3 when the temperature rises, the upper die is pulled up and the lower die is closed.
4 pour into the material, and then the upper mold and the lower mold closed, about one to two minutes, the egg can be formed.
5 pull up the upper die, the lower die, the egg will automatically fall into the passage and slide out.
6 repeat the above process, when not in the end, timely cleaning up and down the mold, keep clean, and then unplug the power supply.
Technical parameter
Model | Power | Voltage | Output | Weigh t | Size | Baking cycle |
DST-2 | 1.6kw | 220v | 50-60 per hour | 45kg | 450*350*700mm | 1-2 minutes |
DST-4 | 3.8kw | 220v | 100-120 per hour | 80kg | 430*430*650mm | 1-2 minutes |
DST-10 | 5kw | 220v | 250-300 per hour | 180kg | 760*600*1050mm | 1-2 minutes |
DST-12 | 9kw | 220v | 300-350 per hour | 200kg | 800*780*880mm | 1-2 minutes |
DST-24 | 12kw | 220v/380 | 600-800 per hour | 280kg | 1050*800*900mm | 1-2 minutes |
DST-32 | 15kw | 220v/380 | 800-1000per hour | 320kg | 1200*800*900mm | 1-2 minutes |
1. Quality Guarantee | one-year guarantee period for each machine |
2.Pretesting before forwarding | All machines will be pretested to make sure it will be received in good condition |
3.Operation Video | We will provide you operation video and detailed instructions to install and you can make full use of the machine |
4.Full Technical service | Engineer is ready to providing you our full-process tracing |
1. Quality Guarantee | one-year guarantee period for each machine |
2.Pretesting before forwarding | All machines will be pretested to make sure it will be received in good condition |
3.Operation Video | We will provide you operation video and detailed instructions to install and you can make full use of the machine |
4.Full Technical service | Engineer is ready to providing you our full-process tracing |
1.Manufacturer for ice cream cone wafer making machine | |
2.Alibaba Assessed Gold Supplier | |
3.100% Quality control before forwarding | |
4.Competitive price with the best quality and service |
if you have any qurestion ,pls let me know
1. Are you manufacturer?
Yes, we are. Welcome to visit our factory.
2. Can you change the machine voltage as our request?
Yes, we can.
3. How about your after-sales service?
Our engineer can go outside to install and train your workers to operate the full machine line.
4. Warranty time of your machine?
1 year except for consumable spare parts.
5. How about delivery time of your machine?
Generally it needs 5-7 days for big machines or producing line,and it will be much longer but within our negotiated delivery time.
