Product Details
| Brand Name | MONA | Place of Origin | Henan, China | |
| Model Number | MN-009 | Certification | CE ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas | Warranty | One Year | |
| Weight | 1950 | Dimension(L*W*H) | 2280*2000*3000mm | |
| Condition | New | Voltage | 380V | |
| Power(W) | 3 | Processing Types | Grape fruit |
Product Description
Pratical Ice Grape juice Machine/ice wine press
details for the machine
Baskey type ice wine press machine is one of the special equipment for brewing ice wines. This machine is absorbed the technology of Italy. Hydraulic automatic control, then juice dribbling moving wheels, manual hydraulic lift, easy operation. The basket is composed of two semicircles. The wooden structure and stainless steel plate punching two structural forms. The wooden structure of the tradition of the ancient structure of the European brewing ice wine, classic elegance. The structure of the stainless steel plate punching nice. The user can either. Quick opening locking device, easy to operate, fast. The machine for ice grape juice, you can also adapt to any excluding large shaped stone fruit to extract the juice and vegetable processing, to adapt to a wide.
Structure and working principle:
This machine consists of main machine, hydraulic system, mobile juice store plate, the basket.
The juice store plate installed in the frame of dolly with the wheel. The basket is on the juice store plate. After the put grapes into the dolly, then boost it under the mobile platen. The grape will be extruded juice under the pressure of the mobile platen .
details parameters :
Model | MN-009 | MN-010 |
Capacity | 0.7t/h | 0.5 t/h |
Power | 3 KW | 3 KW |
Working Pressure of Cylinder | ≤25Mpa | ≤25Mpa |
Maxmium Bearable Pressure | ≤30Mpa | ≤30Mpa |
The route of Piston Rod | 870mm | 700 |
Diameter of Basket | 1000 mm | 800 |
Height of Bsket | 1100 mm | 950 |
Volume of Bsket | 780L | 470L |
Dimension | 2280×2000×3000mm | 1925×1800×2665mm |
Weight | 1950kg | 1600kg |
Product Shows
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Zhengzhou City, China.You can fly to Zhengzhou airport directly.All our clients,
from home or abroad, are warmly welcome to visit us!
3.Q:How can I get some samples?
A: We are honored to offer you samples.
4.Q:How does your factory do regarding quality control?
A:"Quality is priority. we always attach great importance to quality controlling from the very beginning to the very end.
Trade Terms:
- Payment: T/T, LC; 30% deposits; 70% balance before deliverying.
- Delivery Time: 15-60 days
Why Choose Us?
We make domestic, agricultural and industrial hand sprayers in a huge variety of styles. Established in 1978 and holding an AAA credit rating, our reputation rests on a threefold foundation: our products, prices, and people.
We have a long history and strong technology in this, and use a complete set of advanced equipment and technology. With good performance and novel styles, have become well known at home and abroad.
With our sprayers popular among clients, our "MONA" trademark is famous worldwide. Besides China, our sprayer items are now exported to Hong Kong, the USA, Canada, Central and South America, Europe, Southeast Asia, the Middle East, Africa and Australia, etc.
If you are interested in any of our products, please feel free to contact us for more information. We are looking forward to forming business relations with customers domestically and internationally.
