Roller Kiln Double-Layer Natural Gas Roller Kiln

Roller kiln Double-layer natural gas roller kiln

Now the company can supply one kind of double-layer natural gas roller kiln with energy conservation and full automation,the price will be very preferential . This kind of roller kiln is suitable for continuous production line, this kiln adopts reasonable fabrication segment by segment , combined with new type of advanced technology at home and abroad, on-site installation and connection are easy, ensure the accuracy of the quality, shorten the installation time, it can save more energy, energy consumption is very low with high yield,it covers a small area, the output of one roller kiln is equivalent with the one of twelve kilns,it mainly aims at the production and sintering of ceramic products which is the best choice for large-scale manufacturers.
The brief parameters of double-layer natural gas roller kiln
Total length of kiln :150m
Length of preheating zone:32m
Length of firing zone:68m
Length of cooling zone:50m
The length of every segment:2.5m
Inside width of kiln:2.9m
Height for the heat-dispersing surface of preheating zone :1.33m
Width for the heat-dispersing surface of preheating zone:3.66m
Height for the heat-dispersing surface of firing zone:2.0m Width for the heat-dispersing surface of firing zone:3.94m
Firing period: Adjustable between 8 and 24 hours
Rated temperature :1300oC
Heating fuel :Natural gas
Temperature difference in the kiln:±50C
Drive mode:Helical gear segmented transmission

Way of temperature control:control through PID intelligent automatic instrument which can realize full automatic control+whole-process monitor
The type of roller: silicon carbide roller and high alumina roller
The centralized electric control system of double-layer natural gas roller kiln can monitor the whole production process, including the combustion system, transmission system of roller kiln and running state of each layer of products in the kiln.
Anyhow, because of the temperature uniformity in the kiln, heat transfer rate and heat transfer efficiency is high which can ensure the realization of the fast burning, also fast burning will ensure the production, reduce the energy consumption and guarantee the product quality, also provide the condition for fast burning. So the roller kiln is  the advanced kiln type with high quality, high yield, low consumption in the various industries which has been used widely more and more,it is the ideal choice for the production of large-scale enterprise.
The above parameters and pictures can be used as reference for the purchasing, various specifications and sizes can be customized according to the requirement of daily production of users. The picture and text are for only for reading,reproduction and reprinting are strictly prohibited.
The kiln and furnace department of Qianjin Enterprise, the professional manufacturer of natural gas roller kiln , the company has industrial furnace qualifications for three countries,that is,China, Japan and Germany, the energy conservation is highly effective, the quality is reliable, the customers don't need to worry anything after using it.
