Steel Horse Economy Y3150 HOBBING GEAR MACHINE
- Qingdao
 - T/T Credit Card

You May Like
-


Steel Horse High Strength Y3180 Gear Deburring Machine
 -


Economy Y3150 Universal Mini Gear Hobbing Machine
 -


Steel Horse High Strength Y3150 Gear Hobbing Machine
 -


Steel Horse High Strength Shaping Y3180 Gear Hobber Machine
 -


Steel Horse Y3180 Gear Making Machine
 -


A Large Number of Low-cost Y3150 Gear Hobbing Machine for Sale

Product Details
| Brand Name | Steel horse | Place of Origin | Shandong, China | |
| Model Number | Y3150 | Type | Gear Hobbing Machine | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas | |
| Weight | 2700kg | Dimension(L*W*H) | 1825x935x1730mm | |
| Voltage | 220,380 | Condition | New | |
| Power(W) | 3kw | CNC or Not | Normal |
Product Description
Economy Y3150 hob
The machine is suitable for processing bulk and single-piece production spur gears, helical gears, worm and sprockets.
This machine has good rigidity, high strength, high precision, easy operation, adjustment and maintenance simple.
Hwasun milling methods can be used milling machining gear, axial or radial can be processed.
Can be configured according to the requirements of customers of Siemens CNC system, complete drum gear and
small taper bevel gear processing machine can also be heightened, lengthened to expand the machining range.
Y3150 gear hobbing machine Main data:
Maximum working diameter: 500mm
Maximum working Modulus: 8mm
Maximum working width: 250mm
Hob maximum diameter / length: 160/160mm
Working table diameter: 510mm
Hob spindle speed / level :40-250RPM / 9
Maximum axial runout tool spindle: 55mm
Spindle taper: Morse 5
Hob center to table distance :235-535mm
Hob centers and work center distance :20-330mm Countertop
External fixation nose to table distance :380-850mm
Table Aperture: 80mm
Maximum swivel turret: 240 °
Arbor Diameter: 22,27,32 mm
Workpiece spindle diameter: 30mm
Main motor: 5.5KM/1500RPM
Machine outline dimension: 2450 * 1272 * 1790
| 1. Our provide oriented after-sales service including the oversea engineers trainning available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where are you. |
| 2. We welcome engineers from your side to learn the technical design and normal maintenance here,this will help your easy in understanding and helpful if you need to be our dealer. |
| 3. However,don't worry,we have our company own CD/Manual to show you along with the machine.So you can learn this from the existing docments to deepen your knowledge and understanding. |
| 4. Anyhow there are another way is through internet video face to face for machine teaching, because of the high development in internet,the world has become smaller and you can easy contact us if any assistance needed. |
| 5. Through all the ways,we will guarantee the service quality and ensure you will be well helped anytime anywhere. |
Steel Horse machine,is a collection of machine development,testing,production,
sales and integration of joint-stock enterprises.Enterprises with an annual output
of 20,000 sets of various types of machine.Our company was founded in 1990,
in 1995 we shareholding system reform, found "Steel Horse Machine"brand.
With our "Steel Horse Machine" Twenty years in the machinery and equipment
manufacturing industry accumulated abundant capital and the introduction of
foreign advanced technology,in 2007 we spent a lot to create "White Horse CNC"
brand.Enterprise products have been metal processing, automotive,military,
aerospace and other key industries widely used.
Steel Horse machine"quality first,faith forever" as the purpose,we willing to
cooperate sincerely with friends at home and abroad for common development.
1. How about your machine quality?We are worry about the quality. RE: New Fuli is a nature brand in CHINA,through our 30 years research in technology,our design including structure and detailed sercurity and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are Brillante machines.And where there are our machines,there are good reputation and terminal user satisfaction.  |
2. Whether the machine price can be more discount RE:1.New Fuli always provide high quality machine,as we know ,oversea market is more important and difficult than domestic market because of communication time costing after sales,So always,our machine has enough qaulity standard to make sure the machine can work more than the real warranty period.In this way ,we will save a lot and think in advance for the clients. RE:2. Actually Accurl also think about our price level,we are sure to provide quality=price and pice=quality ,the matched price and acceptable for the clients and durable for our machines.We welcome your negotiate with us and get a good satisfaction.  |
3. How about your manufactory in CHINA RE:New Fuli located in Ma'anShan CITY,AnHui province who is the leading area in China and also in the worldwide as the center of the metal plate solution machines,We have worked about 24 years in this area and totally have about 250 staffs.Rich experience in this field with professional technical supporting and oriented service. We welcome your visit to us any time.  |
