China Hot Sale SIMENES Vertical Cnc Milling Machine Center 3 Axis Specification VMC5030
- Qingdao Ningbo Shanghai Tianjin
- T/T Credit Card
You May Like
-
High Quality Automatic 3-axis ,4-axis Vertical Cnc Lathe Milling Machine for Sale VMC850
-
3 Axis 4 Axis Vertical Cnc Milling Machine Center for Sale M400
-
Low Cost New Automatic 3 Axis Cnc Vertical Machining Center for Sale VMC5030
-
China New Automatic 3-axis ,4-axis Vertical Cnc Lathe Milling Machine for Sale VMC850L
-
Full Protection Fannuc Siemens High Quality Cnc Milling Machine VMC7032
-
Specifications of Cnc Milling Machine Center VMC850L
Product Details
| Brand Name | HIENCE | Place of Origin | Shandong, China | |
| Model Number | VMC5030 | Type | Vertical | |
| Certification | ISO CE SGS | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | 1 Year | Weight | 2100KGS | |
| Dimension(L*W*H) | 1900*1800*1900mm | Voltage | 380V | |
| Condition | New | Power(W) | 2.2KW/3.7KW |
Product Description
3 axis high precision vertical cnc machining center for sale VMC5030
A.Standard Configuration and specification
LNC system from Taiwan, Optional SYNTEC, GSK, KND, SIMENES,
6 tool ATC
Box way type guide rail, optional linear guide rail
Taiwan BT40 spindle unit
Precision ball screw
Coolant system, Self lubrication system. Lighting system
Items | Specification of VMC5030L | |
Table size(mm) | 630×280 | |
T type groove (Number-width(mm)–gap(mm)) | 3-14-80 | |
The workbench maximum load(kg) | 300 | |
Travel of X axis (mm) | 500 | |
Travel of Y axis(mm) | 280 | |
Travel of Z axis(mm) | 400 | |
The spindle end to the work surface(mm) | 100-500 | |
The center of spindle to guide rail face(mm) | 395 | |
Taper hole of spindle | BT30 | |
Highest speed of spindle(Rpm) | 100-8000 | |
Power (kW) | 3.7 | |
Rapid feed speed of X/Y/Z axis (m/min.) | 15/15/12 | |
Fast cutting speed of X/Y/Z axis(m/min) | 10/10/5 | |
Width of Wire rails X/Y/Z(mm) | 20 | |
Accuracy
| positional accuracy (mm) | 0.01 |
| repeated positioning accuracy (mm) | 0.008 |
ATC | Capacity | 6 tools |
| Max tool size | 120 |
| Max tool weight | 6kg |
Weight(kg) | 2000 | |
Dimension(mm) | 1900×1800×1900 | |
Voltage | 3 phase 380V | |
B.Pictures of VMC5030
