VMC7032 Machining Center Specification and Cnc Turning Milling Machine With ce
- Qingdao Shanghai
- T/T Credit Card
You May Like
-
Mini China Cnc Milling Machine VMC3020
-
High Speed ! Cnc Vertical Machining Center With ce Good Price VMC850
-
High Speed 6000rpm Cnc Milling Center With Siemens System VMC850
-
VMC7032 Cnc Machine Center or NC Automatic Tool Changing 3 Axis or 4 Axis
-
Cnc Machine Center Price VMC7032 With Siemens Fanuc 4-axis 5-axis
-
VMC7032 Vertical Mini Cnc Center / 16 Tools Small Turning Center With Fanuc
Product Details
| Brand Name | HIENCE | Place of Origin | Shandong, China | |
| Model Number | VMC7032 | Type | Vertical | |
| Certification | ISO CE | After-sales Service Provided | Engineers available to service machinery overseas | |
| Warranty | one years | Weight | 2500KGS | |
| Dimension(L*W*H) | 2500 2250 2300 | Voltage | 380V | |
| Condition | New | Power(W) | 3.7KW 2.2 KW 5KW |
Product Description
Machining center speicification and cnc turning milling machine with ce
CNC milling machine
1..16 tool magazine
2..CNC System fanuc siemens GSK
3. ISO CE
4.High speed /Precision, good efficiency
Main specification
Specification | UNIT | XH7132A |
Table size | MM | 920*320 |
Spindle hole taper |
| BT40 |
Travel range | MM | 620*350*500 |
NO./width/distance of T-slot | MM | 3-14-85 |
Max.load of table | KG | 500 |
Distance from spindle nose to table surface | MM | 100-600 |
Distance from spindle axis to vertical guideway | MM | 395 |
Rapid feed speed | M/MIN | 18 |
Feed speed | MM/MIN | 2.5-3000 |
Spindle speed | R/MIN | 40-6000 |
Spindle motor power | KW | 3.7 |
Max tool weight | kg | 8 |
Tool magazine capacity | piece | 16tools |
Max tool size | mm | Φ120*200 |
Positioning accuracy | MM | ±0.015 |
Repeat position accuracy | MM | ±0.0075 |
Overall dimension(L×W×H) | MM | 2500×2260×2300 |
Net weight | KG | 2540 |
Controller |
| GSK25I Or siemens808D |
Main configuration
1.Cnc system:GSK25i or siemens808D
2.Bamboo hat type(16)tool magazine
3.Ball screw:taiwan precision ball screw.
4.Protection:stainless steel internal protection and full out protective

Faster delivery security
All the goods are suitable for shipping, air transport, railways, road transport
Fumigation of wood packaging
Specific details contact salers( Different model, different weight /size)
Container size
20GP:6058mm(L)X2438mm(W)X2591mm(H)
40GP:12192mm(L)X2438mm(W)X2591mm(H)
40HC:12192mm(L)X2438mm(W)X2896mm(H) Packaging Details


Shipping Details


The buyer received the goods smoothly

Applications of CNC machine tool has been from the airline industry sector gradually expand to the automobile, shipbuilding, machine tools, construction machinery manufacturing industry.
For copper, aluminum , iron, plastic and other precision parts manufacturing, applicable to instruments , watches, cars, motorcycles , bicycles , eyewear , stationery , hardware, sanitary ware, electronic components , connectors , computers, cell phones , electronics, military and other industries in bulk machining small parts, especially the more complex parts.
The company has carried out ISO QMS, We according to the Europen CE certificate classified the production process in programmable.All the produce of parts by CE directive supervise each process. Our machine High- speed , highprecision, small cnc lathe machine, mini cnc lathe machine. There are heavy duty cnc lathe machine.
The proucts sell well in the domestic maket, and menwhile, they have been exported to Europe,America, Southeast Asia and othe countries,more than 50 countries in Worldwide.
The company adjacent to three estuaries of Qingdao ,Shanghai lianyungang Port as well as qingdao, jinan,shanghai Airport.
Company certificate
Choose Hiscience cnc lathe resons
Reason 1. High Precision
All machinery that are launched by ZMaT, has tested with laser interferometers, dynamic balancing instruments and other advanced manufacturing equipment and measuring instruments
Reason 2. High Stability
All machinery base that launched by Z-MaT
have went through aging treatment for at least two years.
Reason 3. Well-known brand
The proucts sell well in the domestic maket, and menwhile, they have been exported to Europe,America, Southeast Asia and othe countries,more than 50 countries in Worldwide.
Reason 4. Flexibility
Because we are one of the few machinery company that have product line of more thant 70 CNC machine tools in China, so that we can choose the best CNC machine tools for our customers. We have a strong R&D team, so that we can design specific machinery to satisfy customers' requirements.
Reason
5. On time
We always deliver machinery on time so that our customers does not need to waste extra time to wait. We also respond our customer at the first time in order to satisfy customers' requirement.
