ZLJ350 Grouting Recommencement Drilling Rig

FOB Price

US$ 1200 - 1300 / Set

1 Set(Min. Order)

Port qingdao
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	huaxiamaster	Place of Origin	China
Model Number	ZLJ350	Type	Core Drilling Rig
Certification	ISO	After-sales Service Provided	Engineers available to service machinery overseas
Weight	430kg	Dimension(LWH)	12306301280mm
Power Type	Diesel	Voltage	220
Usage	Water Well	Condition	New
Power(W)	5.5kw

Product Description

1.The brief introductions of ZLJ350

ZLJ 350 grouting reinforcement drilling machine is mainly used for grouting reinforcement hole. ZLJ350 drilling machine work for under mine, tunnel, subway, slope support. The machine can work different angles of grouting reinforcement and drilling hole.

This drill rig adopts mechanical drive, hydraulic feed with small size, light weight, The rig is reliable and convenient to operate.

1. The specifications of ZLJ350

Drilling diameter	50-113mm
Drill rod caliber	42mm
Noncoring bit	50-113mm
Core bit	56-113mm
Vertical rated speed	340 /192/112 r/min
Vertical shaft torque rating	130/ 230 /400 n.m
Main shaft angle	0-360
Spindle stroke	400mm
System pressure rated	8mpn
Feed force	9kn
Elevating power	12kn
Winch lifting capacity	7.35kn
Capacity of drum	26.8m
Diameter of wire rope	.85mm
Oil pump type	YBC-12/80
Motor power	5.5kw
Dimension	12306301280mm
Total weight	430kg
