Rotary Disk Sorting Machine for Long Screws

Feature:

For M8~M16 screws and bolts, under head length 125~250mm

Available for 2~7 cameras

Optional: wheel crack checking system (LS-1501) for head crack inspection

Optional: Bending checking module

Optional: 360°rotation module for thread damage inspection

Optional: two kinds of Eddy current systems:

 1. For head open crack inspection

 2. Material mix-up or with/without heat-treatment

Sorting items:

? Screw-head height, width ? Recess depth ? Pinhole Excess Material

? Ineffective thread length  ? Minor Thread Diameter ? Feature Angle

? Major Thread Diameter  ? Pitch Distance ? Feature No.

? Bevel Thread ? Screw Length ? Feature Similarity

? Cone Point ? Zinc:Yes or No（Head Top View） ? Feature Length

? Pinhole Alignment ? Head Crack ? AF/AC

? Head Mark ? Roundness ? Material Mix-up

Inner Roundness ? Inner Concentricity ? Broken pin

? Inner Excess Material ? Shorten AF ? Deformed Thread

? Feature-Center Distance

Optional Function:

? Bottom Sorting

? 360° Thread Damage ? Head Wheel Crack ? Screw Bending (Multi-Images)

Specifications:

? Wire Diameter:φ8~16mm ? Head Width:φ10~35mm

? Length Under Head:60~250mm ? Sorting Precision:±1pixel

? Head Height: 5~30mm ?Sorting Speed:60~100/PPM
