GD-17144 ASTM D4530 Gold Micro Carbon Residue Analyzer

Introduction:

GD-17144 Micro Method Carbon Residue Analyze is designed and made as per GB/T17144-1997 Test Method for Carbon Residue of Petroleum Products-Micromethod.
GD-17144 Micro Method Carbon Residue Analyzer is suitable to determine the the amount of carbon residue of petroleum products.

I. Main Technical Features

1. GD-17144 Micro Method Carbon Residue Analyzer adopts all-in-one structure. It consists of two parts: electrical control chamber and high temperature heating furnace. The design is simple and reasonable.

2. GD-17144 Micro Method Carbon Residue Analyzer adopts single chip machine system. The instrument controls the whole procedures automatically according to program preset.

3. The screen adopts all English interface. Operator can do determination by prompts on the screen even no need to read the operation manual. Easy to operate.

4. GD-17144 Micro Method Carbon Residue Analyzer controls the flow rate of nitrogen, temperature heating rate and preset temperature automatically. Easy to adjust the flow rate. The heating rate is accurate and temperature control is stable.

5. GD-17144 Micro Method Carbon Residue Analyzer collects test data and calculates results automatically. It can print and save the data according to customer’s requirements.

6. The measurement range of this instrument is 0.10%(m/m)~30.0%(m/m). The test result is equivalent to Conradson method if the carbon residue is higher than 0.10%(m/m).

7. The instrument can also be used to determine the petroleum products composed of distillate oils which carbon residue is lower than 0.10%(m/m). But the specimen shall be sampling to 10%(V/V)distillation residue according to GB/T6536 firstly.

8. GD-17144 Micro Method Carbon Residue Analyzer equips a electric balance to achieve the automation of sample weighing and data input.

II. Main Specs

1	Power supply	AC(220±10%)V, 50Hz
2	Maximum power consumption	1600W
3	Temperature of coke chamber	500℃
4	Temperature control accuracy	±2℃
5	Heating power	1500W
6	Ambient temperature	5℃~35℃
7	Relative humidity	≤85%;
8	Dimension	520mm×360mm×525mm

III. Packaging List of ASTM D4530 Gold Micro Carbon Residue Analyzer

No.	Product name	Unit	Quantity	Remark
1	GD-17144 Micro Carbon Residue Value Analyzer)	Set	1
2	12 Holes Tube Rack	PC	1
3	Big sample tube(Dia.12×70mm)	PC	24
4	Small sample tube(Dia.12×35mm)	PC	24
5	Test Tube Hanger	PC	1
6	Air manifold(Inner Dia. 6PU 2m)	Set	1	Connect steel cylinder and main unit
7	Discharge pipe(Inner Dia.10PU 2m)	Root	1	Discharge the smoke
8	Electronic balance(110g; readability 0.1mg)	Set	1
