Home > Products > Insulation paper > NHN (6650) electric insulation paper with UL/ROHS certifucation
NHN (6650) electric insulation paper with UL/ROHS certifucation
- 1000000 Kilogram / Kilograms per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 5 days
You May Like
Product Details
| Brand Name | Pioneer | Place of Origin | China | |
| Model Number | 6650 NHN | Material | Composite Polymer | |
| Type | Insulation Paper | Application | High Temperature |
Product Description
6650 NHN insulation paper consists of two layers of Dupont Nomex paper and one layer of polyimide in the center, the used adhensive is C CLASS ,acid-free and temperature resistant. The polymide film giving the product mechanical and dielectric features, while the Du Pont Nomex paper gives the thermal resistance.
- The nomex insulating paper is Class H insulation (180C)
- The nomex insulating paper has Excellent dielectric and mechanical property, even better properties of dielectric and mechanical under high temperature and after humidity
- The nomex insulating paper can be us slot, interturn and liner insulation for H-grade motor and electric appliances
Properties | Unit | Values | |||||||
Product Name | 6650 NHN Insulation Paper | ||||||||
Nominal Thickness | mm | 0.15 | 0.17 | 0.20 | 0.23 | 0.25 | 00.30 | 0.33 | |
Thickness Tolerance | mm | ±0.02 | ±0.03 | ±0.04 | ±0.05 | ||||
Breakdown Voltage (No Bending) ≥ | KV | ≥ 8 | ≥ 9 | ≥ 10 | |||||
Bond Strength At Room Temp. | — | No delamination | |||||||
Bond Strength At (200±2) ℃, 10 min | — | No delamination, No blister, No adhesive flow | |||||||
Long-term Heat Resistance (TI) | ℃ | ≥ 180 | |||||||
