Plastic Recycling and Granulation Line/plastic Pelletizer Price

1.This line is used to pe pp hdpe ldpe lldpe plastic film pelletizing machine.It is consist of Feeding conveyor belt,Metal detector,Cutter compactor force feeding,palstic extruder,Hydraulic screen exchanger,vertical dewatering ,Air conveyor system,storage silo and so on.

2.The line is double stage ,we also can supply single stage to customer.the screw was made by 38CrmoAla and treatment by Nitriding .

3.we supply 150~1000kg/h or customized the capacity

Used pp woven bags granulating making machine/pe plastic film pelletizing machine

1.PE PP film recycling granulating machine is special equipment for the PE PP film recycling granulating, it equipped with compacting machine which could pre- compact the film into smaller granules, it is easily to feed into screw barrel of extruder. It also can improve production capacity and save labour cost.

2. Extruder barrel have two vacuum exhuast mouth which can fully remove the moisture and hence the final granule quality will be very perfect.

3. This line adopt water cooling pelletizing

Detailed description of Used pp woven bags granulating making machine/pe plastic film pelletizing machine

1. Conveyor:Conveyor plastic film/woven bags into compactor machine

2. Plastic Compactor:crushing and compactor plastic film/wocen bags

3. Extruder system:plasticizing material and exhausting gas.

4. High speed Net exchanging system and Die-head:filter material impurity and extruder noodle

5. Water cooling tank:cooling extruder noodle

6. Pelletizer:cut noodle

7. Vibration sieve:remove bad pellet and keep good pellet.

8. Air Blower:convey good pellets into silo.

9. Storage silo:collect pellet

Packaging & Shipping

1.For the loose cargo we will packing by wooden box

2.For the full container loading we are packing the machine by film and some on pallet accordingly

3.We can shipping the goods by air or by sea

4.We will send pictures of cargo loading to our client to check and keep recording

5.We can send cargo to client’s warehouse to loading

Our Services

1.Pre-sale: we given client the details technician offer, sign the sales contract etc

2.In-sales: we supply the details layout, installation instruction, technician support for the clients

3.After sales: we arrange engineer to install the machinery and training the workers for client

4.We have 24hours team to solve the after sales problem

5.We have free spare parts with the machine

6.We supply long term spare parts for every customer

7.We always up date the new technology to every customer
