Single-shaft Shredder (RS3080)

RS Single-shaft Shredder is one of the most versatile and widely used crushers. Material can be fed directly with dosing. In most applications, it can operate without an additional feeding system. High-volume hopper of alternative structure and hydraulically driven ram effectively prevent material from running and wandering about, thus ensures low noise level, high efficiency and speed shredding. The intelligent design in low speed rotor and adjustable blade-mounts makes the shredding process extremely easy for material in shapes of bundle, strip, scroll, and entanglement.

Design

A. Material can be directly fed from high-volume hopper
B. Hydraulically driven ram drives material towards rotor
C. Rotary cutter tears material up, and with stationary cutters performs interactive shredding
D. Screen with multiple options of mesh diameters, ensuring product size up to customer’s requirement

Feature

● Low speed rotor, high torque-level
● Noise and dust free
● Hydraulically driven ram and force-feeding swing arm
● 180° rotating, high cutting performance
● Swing-arm installement of gearbox and micro-switch detection for protection of gears and engine
● 100% imported blades of SKD11, D2, DC53 and ASP60 show high strength, high abrasion resistance and long service life
● 80-100 hour test under “real-life” condition, high reliability

Applications

● Plastic: HDPE; purging; PET bottles; film (loose packing, bales or scrolls); foam plastic; sponge; fiber-glass; plastic packaging; plastic tubes; CD/DVD; waste baskets; bumpers;  dash boards; mobile phone shells
● Rubber: rubber block; rubber blanket; rubber tube; sealing; bladder; tyre tube; rubber fiber; rubber rolls
● Textile: clothing; fabric; leather; carpets
● Paper: paper waste (loose packing or piles); card-boards; corrugated paper; boxes; cardboard tubes; tetra packaging
● Wood: lumber; pallets; furniture
● Electronics: circuit board; hard disk; toner cartridge
● Metal: UBC; punched scrap
● Cables with aluminum or copper conductor
