china chart projector vision tester

ACP-300 Auto Projector can provide 30 types of clear icons with different functions, and can program icon groups per specific needs. It can produce more precise measurement results in shorter time by remote controller and fast toggling icon, applying red/green & polarized icon test sheet, binocular eyesight and binocular balance.

Specifications:
Projection distance:1.5m ~ 6m
Projection magnification:30 x (at 5m)
Projection size:330mm(W) x270mm(H) (at 5m)
Chart :30 different pattern
Speed of chart conversion:One chart per 0.03s
Mask:1 open,5 horizontal lines,8 vertical lines,21 single letters, 1 red/green
speed of mask conversion:One mask per 0.03s
Program:2 sets programs, each program contains up to 30 steps
Light source:12V,50W Halogen Lamp
Auto-off function:After 10 minutes idle time.
Power source:AC 220V ,50Hz or 110V, 60Hz
Power consumption:80W
Dimensions:300mm(L) x 230mm(W) x 240mm(H)
Net weight:6Kg
Accessories:Remote control, Polarized metal screen, halogen lamp, polarized glasses, fuses(2), batteries(2)
Optional accessories:Floor stand, wall stand
