YHZS50 Mobile mixing station

Product introduction

YHZS50 Mobile mixing station is mainly made up of the host chassis, control room, aggregate batching metering, belt conveyor racks, peripheral components and JS-type forced-type mixer of six major components. YHZS 50 Mobile Mixing station theoretical output value is 50 cubic meters per hour. The host is the use of JS1000-type forced mixer, which is widely used in highway, bridge, port, hydropower and other engineering mobile construction.

Performance advantages

First, the system is more secure.

1. YHZS 50 Mobile station electrical layout and line installation fully consider security, and many places equipped with safety switches to minimize the risk of personnel.

Second, the operation is more reliable.

1. There are professional embedded computer, strong environment adaptability ( -25-70℃), and stable operation;

2. The professional customized computer operation system, which can repair the diagnosis to ensure that the system operation worry-free;

3. Hand/automatic production switches to meet a variety of requirements, reaching to the full automatic production;

4. The belt machine can load to start, which greatly facilitates in the accidental power failure again starts, to make the belt machine material clean;

5. The control system has a temporary power outage database automatic backup function, which effectively prevent data loss.

Third, the function is more powerful.

1.  It has the manual production data record function to comprehensively solve the human loses the data;

2. The automatic storage function, marking operator's operation process;

3. It is automatic expansion and embedded user network management system;

4. Equipment automatic maintenance and maintenance early warning system, to remind you to maintain timely maintenance at all time.

Technical parameters

Theoretical productivity (m3/h): 50m3/h

Stirring host: JS1000

Batching Warehouse: 6×4

Belt Conveyor Conveying Capacity (h): 400

Towing speed (km/h): 15

Tread (outside) (mm): 3400

Turning radius (mm): 15

Weight of Machine (kg): 25000

Total Power (KW): 60

Discharging height (m): 2.8
