125kw Marine generating sets 6CT8.3-GM155-50Hz
- T/T L/C D/P D/A
- 7 days
You May Like
Product Description
Marine generating sets
125kw Marine generating sets 6CT8.3-GM155-50Hz
use:Marine
Frequency Hz:50Hz
YK Model::kms125pm
Product Name:125kw Marine generating sets -50Hz
Model:6CT8.3-GM155
Prime Power(kw/Kva):125/156
Standby Power(kw/Kva):138/173
Rated Current A:180
Open type Dimension(L*W*H) mm:21002210*800*1290
Open type Weight Kg::2200
Manufacturer:Cummins
Model:6CT8.3-GM155
Exhaust8.3
Continuous/StandbyKW):115/127
Aspiration & Cooling:Turbo
Cylinders Capacity Lt :6
Cylinders & Build :In line
Speed RPM :1500
Bore & Stroke mm×mm :114×135
Compression Ratio:16.5
Governor :E
Fuel consumption g/kw.h :206
Fuel consumptionL/h:31
Lub-oil Capacity Litre 23.8
max oil temperature 121
Coolant Capacity Litre 26
Cooling methodheat exchanger
Max intake resistancekPa)6.2
Max exhaust back pressure10
Flue gas temperature 534
Thermostat82-93
Stamford Model UCM274G
Excitation:PMG
Output Voltage V :400/230
Steady Voltage Adjusting Range:±1%
InsulationH
ProtectionIP23
Ventilation cooling capacity1/s)514
Rated capacityV)24
