Carbide End Mill , 16-20mm 4 Flute , TiSiN Coating , Flat end mill, upto HRC55 ,
- T/T L/C D/P D/A
- 7 days
You May Like
-
Carbide End Mill , 18-14mm 4 Flute , TiSiN Coating , upto HRC55 , carbide cutter
-
11mm , 4 Flute , Square End Mill , SiN Copper Colour , upto HRC55 , CNC end mill
-
9mm *4F Square End Mill SiN Copper Colour , upto HRC55 , end mill supplier
-
Milling Machine Tools Carbide End Mill Cutter With 0.5 - 0.6 UM Grain Size H6 Tolerance
-
Tialn / Altin / Tisin Coating Square End Mill With Solid Carbide Material
-
High Precision Cnc Milling Cutter / 0.5UM Grain Size 4 mm End Mill Cutting Tools
Product Details
| Brand Name | INMIND | Place of Origin | China | |
| Model Number | 20*45*20D*100L*4F |
Product Description
Certification:SGS
Description:
Quick Detail:
0.5-0.6um Ultra-Fine grain size solid carbide end mill
TIALN Coating (Purple),SiN(Copper), AlTiN ( Black)
Made by 5 AXIS CNC grinder
Checked by Zoller Inspection Equipment
Workpiece upto HRC55
1 piece packing.
Standard Length Type
Carbide Rod:Wc:88%,Co:12%,TRS:4000N/mm2, Grain Size:0.5-0.6um
| custom high quality carbide end mills | |
| Creative excellence, speed to market, seamless delivery – whatever your challenge, can be meet! | |
| End mill type | Solid Carbide Square end mill, ball nose end mill, corner radius endmill,Aluminium end mill,end mills for stainless,Mulit-Flute power endmills,roughing end mills, Micro end mill, Long neck end mills, taper flute end mill, Muti-Fuction end mill,chamfer end mills, drills,step drills,reamer,spotting drills,No-Standard cutter. |
| Carbide Rod |
Micro Grian size 0.6-0.8um, TRS:3500N/mm2,HRA91.5-91.8 Ultra Fine Grain Size 0.5-0.6,TRS:3800-4000N/mm2,HRA92-92.2 WF25 Super Fine Grain Size 0.4um,TRS:4000N/mm2,HRA92.5 ,K44 Super Fine Grain Size 0.3um,TRS:3800-4000N/mm2,HRA93.8, K55 |
| Grinding Machine | Walter(Germany), Michael Deckel(Germany), ANCA(Australia), |
| Size |
Diameter:1mm-25mm, Length(AOL):38mm-300mm, Effective cutting length: within 150mm, For Micro End Mill:0.1mm to 0.9mm |
| Surface Coating | TIALN,ALTIN,SIN,TISIN,BALINIT@ X.CEED,BALINIT@ ALCRONA PRO |
| Series | X-Series U-Series S-Series, Super S-Series |
| Finishing treatment | Polish,surface passivation,remove droplet of coating |
| Drawing format | Autocad,PDF, JPEG,Adobe Illustrator, Photoshop, |
| Packing details | 1PCS PVC Single Packing, 10pcs packing again, |
| MOQ | 100pcs Per Size |
| Delivery time | 7-8 work days after confirm order |
| Payment Terms | T/T, PayPal ,Western Union, etc |
| Shipment | DHL/FedEx/UPS for small package, or shipped by sea/air to you which is nearest to your address |
Applications:
Fit for milling quenching and tempered steel.stainless steel.nickel alloy and Titanium alloy,Cast iron,enhanced composited material with fiberglass,Also fit for milling copper.
Specifications:
| Order No | Cutting Dia | Cutting Length | Shank | AOL |
| d | l | D | L | |
| 20×45×20D×100L×4F | 20 | 45 | 20 | 100 |
other standard size is also in stock (1mm to 12mm)
| 3.0×8×4D×50L×4F | 3 | 8 | 4 | 50 |
| 3.5×10×4D×50L×4F | 3.5 | 10 | 4 | 50 |
| 4.0×11×4D×50L×4F | 4 | 11 | 4 | 50 |
| 3.0× 8×6D×50L×4F | 3 | 8 | 6 | 50 |
| 3.5×10×6D×50L×4F | 3.5 | 10 | 6 | 50 |
| 4.0×11×6D×50L×4F | 4 | 11 | 6 | 50 |
| 4.5×13×6D×50L×4F | 4.5 | 13 | 6 | 50 |
| 5.0×13×6D×50L×4F | 5 | 13 | 6 | 50 |
| 5.5×13×6D×50L×4F | 5.5 | 13 | 6 | 50 |
| 6.0×15×6D×50L×4F | 6 | 15 | 6 | 50 |
| 7.0×16×8D×60L×4F | 7 | 16 | 8 | 60 |
| 8.0 ×20×8D×60L×4F | 8 | 20 | 8 | 60 |
| 9 ×20×10D×75L×4F | 9 | 20 | 10 | 75 |
| 10×20×10D×75L×4F | 10 | 25 | 10 | 75 |
| 11×25×12D×75L×4F | 11 | 25 | 12 | 75 |
| 12×30×12D×75L×4F | 12 | 30 | 12 | 75 |
