Home > Products > Ball Nose End Mill > Milling Machine Tools Ball Nose Long End Mill Bits With TiSiN Coating Surface
Milling Machine Tools Ball Nose Long End Mill Bits With TiSiN Coating Surface
- T/T L/C D/P D/A
- 7 days
You May Like
-
0.5 - 0.6 um Mirco Grain Solid Carbide Ball Nose End Mill , Ball End Mill Cutter
-
Long Flute Ball Nose End Mill with 100 mm Length 10 mm Dia 0.5 - 0.6 UM Grain Size
-
SiN Coating Long Ball Nose End Mill R6*150 , Dia 12 mm AOL 150 mm HRC55
-
HRC55 Long Shank Type Ball Nose End Mill With SiN Coating , H6 Tolerance
-
Upto HRC50 AlTiN Coating , 1mm to 4mm Square End Mill , 4 Flute , Carbide end mill , Grain Size 0.8U
-
AlTiN Coating 1.5mm to 6mm hard milling end mills , 4 Flute end mill bits high precsion
Product Details
| Brand Name | INMIND | Place of Origin | China | |
| Model Number | R4*16*8D*100L*2FU |
Product Description
Certification:SGS
Quick Detail:
0.5-0.6um Mirco grain size solid carbide rod
TIALN Coating ,high Aluminium (Black),Middle Aluminium(Purple)
Made by 5 AXIS CNC grinder
Checked by Zoller Inspection Equipment
Workpiece upto HRC50
1 piece packing.
Standard Type
Applications:
Fit for milling quenching and tempered steel.stainless steel.nickel alloy and Titanium alloy,Cast iron,enhanced composited material with fiberglass,Also fit for milling copper.
Description:
Ultra-Fine Grain Szie 0.5-0.6um, Wc carbide rod with high tenacity,with high quality TiAlN coating,getting long tool life,from roughing to finishing processing,reduce time of changing cutters,improving efficency of machine,saving time of making moulds.Suggest to process iron and steel upto HRC55,Middle-High speed.
Carbide Rod:Wc:88%,Co:12%,TRS:4000N/mm2, Grain Size:0.5-0.6um
Specifications:
| Order No | Cutting Diameter | Flute Length | Shank Diameter | A.O.L |
| d | l | D | L | |
| R4×16×8D×100L×2F | 8 | 16 | 8 | 100 |
we also supply other long size ball nose end mill
| Order No | Cutting Dia | Shank | Cutting Length | AOL |
| d | D | l | L | |
| R2.5×10×6D×100L×2F | 5 | 6 | 10 | 100 |
| R3.0×12×6D×75L×2F | 6 | 6 | 12 | 75 |
| R3.0×12×6D×100L×2F | 6 | 6 | 12 | 100 |
| R3.0×12×6D×150L×2F | 6 | 6 | 12 | 150 |
| R4.0×16×8D×75L×2F | 8 | 8 | 16 | 75 |
| R4.0×16×8D×100L×2F | 8 | 8 | 16 | 100 |
| R4.0×16×8D×150L×2F | 8 | 8 | 16 | 150 |
| R5.0×20×10D×100L×2F | 10 | 10 | 20 | 100 |
| R5.0×20×10D×150L×2F | 10 | 10 | 20 | 150 |
| R6.0×24×12D×100L×2F | 12 | 12 | 24 | 100 |
| R6.0×24×12D×150L×2F | 12 | 12 | 24 | 150 |
| R7.0×28×14D×150L×2F | 14 | 14 | 28 | 150 |
| R8.0×32×16D×150L×2F | 16 | 16 | 32 | 150 |
| R10×40×20D×150L×2F | 20 | 20 | 40 | 150 |
Competitive Advantage:
Good and Stable Quality.
New Coating TiSiAlN Improve the performance in high hardness material and stainless steel.
Competitive price.
Help the agent to get the get more large market in the quality products.
Our production capacity
| Production Equipment | Machine Quantity | Product Name | Production Nersonnel | Monthly Output |
| German Walter | 2 | Tungsten Steel Drill,Endmill,Reamer,Thread Mill | Engineer: 2 Poduction staff: 6 |
20000PCS |
| Australia ANCA | 3 | Tungsten Steel Drill,Endmill,Reamer,Thread Mill | Engineer: 2 Poduction staff: 4 |
30000PCS |
|
Germany Michael Deck |
2 | Tungsten Steel Endmill,Reamer | Engineer: 2 Poduction staff: 4 |
20000PCS |
1. Is your company a trading one or a factory?
Factory (We produce, we sell)
2. How long have you done in this industry?
Over 6 years specializing in producing non-standard cutting tools
3. How do I pay for my purchase?
Escrow, Credit card, Western union, Paypal, MoneyGram,T/T, L/C, L/C, D/A, D/P are all accepted.
4. How about the delivery?
10-15 days we took, once you payed.
5. Do you accept trial order?
Sure we can. And we would like to quote our most favorable price if your order is big enough.
6. Is your company accept customization?
OEM and ODM are available. And we have our own professional R&D team servicing for you
Contact : 24-hour online service
