Home > Products > FTTx OLT > 16 PON FTTx OLT 2 10GE/GE SFP+ Optical Port with Pluggable Power Supply EL5610-16P
16 PON FTTx OLT 2 10GE/GE SFP+ Optical Port with Pluggable Power Supply EL5610-16P
- T/T L/C D/P D/A
- 7 days
You May Like
-
Dual Power Fiber To The X Optical Line Terminals 8GE Copper Port EL5610-08P
-
4 PON port FTTx OLT Optical Line Termination 95.23Mpps Ipv4 / Ipv6 Forwarding Capacity
-
256Gbps Backplane Layer 3 Gigabit Switch SFP port With 8Mb Flash Memory S5650-52SM
-
Gigabit Layer 3 Switch Power Over Ethernet With 4 GE Combo 1+1 Redundant Power
-
Telecom IEEE 802.3ah EPON FTTx OLT Terminal Double Power Supply EL7500-16
-
10G Uplink Network 4 10Gbe SFP+ Switch, Layer 2 Managed Switch 24 10/100/1000Base-T S5330-28TX
Product Details
| Brand Name | GCOM | Place of Origin | China | |
| Model Number | EL5610-16P |
Product Description
Certification:CE, FC, UL, CCC
16 PON FTTx OLT 2× 10GE/GE SFP+ Optical Port with Pluggable Power Supply EL5610-16P
Overview
EL5610 series provides 4/8/16 downlink 1000M EPON ports, 8 GE Ethernet ports and 2/4 10G uplink ports. The height is only 1U for easy installation and space saving. It adopts the advanced technology, offering efficient EPON solution. Moreover, it saves a lot cost for operators because it can support different ONU hybrid networking.
EL5610 series is a high integration and medium capacity cassette EPON OLT designed for operators access and enterprise campus network. It follows the IEEE802.3 ah technical standards as well as meets the EPON OLT equipment requirements of YD/T 1945-2006 Technical requirements for access network——based on Ethernet Passive Optical Network(EPON) and China telecom EPON technical requirements 3.0. EL5610 series possesses excellent openness, large capacity, high reliability, complete software function, efficient bandwidth utilization and Ethernet business support ability, widely applied to the operator front-end network coverage, private network construction, enterprise campus access and other access network construction.
Product Specification
| Item |
EL5610-04P |
EL5610-08P |
EL5610-16P |
|
| Switching Capacity | 128Gbps | |||
| Forwarding Capacity(Ipv4/Ipv6) | 95.23Mpps | |||
| Service Port | 4*PON port ,4*10GE/GE SFP+optical port +8GE copper port | 8*PON port ,4*10GE/GE SFP+optical port +8GE copper port | 16*PON,4*GE SFP optical port ,4*GE COMBO port,2*10GE/GE SFP+optical port | |
| Redundancy Design | Built-in double power supply,including AC input,double DC input,AC+DC input,single AC input,single DC input,distinguished via model | Pluggable double power supply,double AC input,double DC input and AC+DC input | ||
| Power Supply |
AC:input100～240V 47/63Hz； DC:input36V～75V； |
|||
| Power Consumption | ≤40W | ≤45W | ≤85W | |
| Dimensions (Width x Depth x Height) | 440mm×44mm×311mm | 442mm×44mm×380mm | ||
| Weight (Full-Loaded) | ≤3kg | |||
| Environmental Requirements |
Working temperature:-10°C～55°C Storage temperature:-40°C～70°C Relative humidity:10%～90%,non-condensing |
|||
