Home > Products > Optical Fiber Adapter > FC Fiber Optic Adapter (FC/PC-SM/MM-D(Big)-Type)
FC Fiber Optic Adapter (FC/PC-SM/MM-D(Big)-Type)
Negotiable
/ Piece
1000 Pieces(Min.Order)
- 100000 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | JINGKON | Place of Origin | China | |
| Model Number | FC/PC-SM/MM-D(Big)-Type |
Product Description
We are manufacturer of optical fiber adapter-FC series products.
FC --type fiber optical adapter detailed information as follows:
1. Product specification
Insertion loss(dB)≤ 0.2
Repeatability(dB)≤ 0.1
Interchangeability (dB)≤ 0.2
Sleeve material: Ceramic or metal
Tensile strength: 200-600G
Operating temperature: - 40o C - +80o C
Storage temperature: -40 - + 85
2. Product description
Fiber optical adapters are used to calibrate two fiber optic connectors. The types of these adapters are FC, SC, LC, ST, MTRJ, MU, E2000
3. Features
Accord with the standard of ROHS
High precise dimension
Ceramic or bronze sleeve
Low insertion loss, high return loss
Interchangeablitily is more than one thousand, repeatibility is less than 0.2dB.
4. Application
FTTX, FTTH
Telecom, access network
Optic fiber CATV
Terminal of the devices and multimedia
Testing and medical devices
Industry and military application
5. Order Guide
Dust Cap Color:
1) Blue 2) Green 3) Black 4) White 5) Red 6) Yellow 7) Beige
Sleeve Material:
1) Z: Zirconia 2) P: Phosphor Bronze
Type:
1) Integrative Squareness
2) Fission Squareness
3) Diamond
4) Rectangle
5) Big D Type
6) Small D Type.
| Trademark: | JINGKON |
| Model: | FC/PC-SM/MM-D(Big)-Type |
| Standard: | ROHS |
| Productivity: | 100 000 |
| Origin: | China |
| Packing: | Carton |
| Min. Order: | 1000 |
| Transportation: | Air or Sea Transportation |
