Cable Connection Diagram
Negotiable
/ Piece
1 Piece(Min.Order)
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Place of Origin | China |
Product Description
|
Way of cable connection | |
|
Take the case of the cabie away make the wire one long and one short, cut down then insurt the pipe.(provide). peel off the lead and motor guiding wire to get 40mm copper center, insurt 20mm. tight with pincers(cover tin on the connection better). encase in the pipe on the connector . cover and make it hot and tighten. cover the connection three to five layers with water-proof stuck rubberized tape. tie the connections together. then cover them three to five layersw with the waterproof self-stuck rubberized tape. At last, cover 1 lager with plastic electrical rubberized tape to protect. Notice for connect the joint. 1.Cable wire and motor guiding wire connect in safe way. 2.The tape pull 200% length before cover. half wide cover spirally the tape will shrink tightenly and waterproof. 3.Keep the joint and tape clean without dirty oil. |
