TAIMES 3208H LARGE FORMAT PRINTER

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 0 Set / Sets per Month
Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TAIMES		Place of Origin	China
Model Number	TAIMES 3208H

Product Description

TAIMES 3208H LARGE FORMAT PRINTER

large format printer

Model No:seiko_printer_3208h

TAIMES 3208H SOLVENT PRINTER Advance Technic:
* Original Japanese drop on demand piezo print head with steel plate protected, 510 active nozzles/print head, 71.8mm printing width.
* 4 color plus 720dpi makes unmatchable color and high resolution.
* The voltage of the print head, automatically adjustable to the temperature, prevents blockage caused by the change of temperature.
* The function of skipping white space is added to increase productivity.
* The adjustment of bi-direction, step and carriage moving speed can be made during printing.
* Edge feather function can blur the pass line and feather the pass edge.
* Delicately designed alloy-aluminum platform.

Product Model	TAIMES 3208H SOLVENT PRINTER
Printhead	SPT510-35PL
Number of Printhead	8 Heads
Maximum Print Width	3200mm
Output (m²/h)	Print Mode	Standard Output (m² /h)
	360x360dpi 1pass	101
	240x720dpi 2pass	76
	240x1080dpi 3pass	51
	360x540dpi 3pass	71
	360x720dpi 4pass	53
	360x1080dpi 3pass	34
	720x720dpi 4pass	26
Ink	Type :	Solvent Ink / ECO-Solvent Ink
	Color :	4 Colors( C , M , Y , K , )
	Capacity :	5L Per Main Tank of Each Color
	Ink Supply System :	Low Ink Detector, Auto or Manual Ink Supply System
Media	Width :	3300mm
Media	Type :	Vinyl,Flex,Polyester,Back-lit Film, Window Film,etc
Auto Media Feeding System	Equipped ( Max. Media Weight 80kg )
Auto Cleaning System	Positive Pressure Cleaning Anti-clogged Flash Function & Capping System
Pre-heating & Drying System	Equipped
Clamp	Equipped
Print Interface	USB2.0
Printhead Height	2 to 4 mm Above Media Adjustable
RIP Software	Maintop , UltraPrint , PhotoPrint , Topaz , Wasatch , Caldera
Input Power	AC 220V ,50Hz/60Hz
Machine Dimension	L4,500x W760 x H1,310 mm Net Weight : 620Kg
Package Dimension	L4,630 x W920 x H1600 mm Gross Weight : 900Kg
Operation Environment	Temperature: 20~28 ^oC Humidity: 40%~60%
