TAIMES 3204D PRINTING MACHINE

FOB Price

Negotiable / Set

1 Set(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TAIMES		Place of Origin	China
Model Number	TAIMES 3204D

Product Description

TAIMES 3204D PRINTING MACHINE

printing machine

Model No:solvent_printer_3204d

TAIMES 3204D SOLVENT PRINTER Advance Technic:
* Original Japanese drop on demand piezo print head with steel plate protected, 255 active nozzles
* 4 color plus 720dpi makes unmatchable color and high resolution.
* The voltage of the print head, automatically adjustable to the temperature, prevents blockage caused by the change of temperature.
* The function of skipping white space is added to increase productivity.
* The adjustment of bi-direction, step and carriage moving speed can be made during printing.
* Edge feather function can blur the pass line and feather the pass edge.
* Delicately designed alloy-aluminum platform.

Product Model	TAIMES 3204D SOLVENT PRINTER
Printhead	SPT255-35PL
Number of Printhead	4 Heads
Maximum Print Width	3200mm
Output (m²/h)	Print Mode	Standard Output (m² /h)
	240x540dpi 3pass	20
	240x720dpi 4pass	15
	240x540dpi 6pass	11
	360x540dpi 3pass	15
	360x720dpi 4pass	11
	360x540dpi 6pass	8
	360x720dpi 8pass	6
Ink	Type :	Solvent Ink / ECO-Solvent Ink
	Color :	4 Colors( C , M , Y , K , )
	Capacity :	5L Per Main Tank of Each Color
	Ink Supply System :	Low Ink Detector, Auto or Manual Ink Supply System
Media	Width :	3300mm
Media	Type :	Vinyl,Flex,Polyester,Back-lit Film, Window Film,etc
Auto Media Feeding System	Equipped ( Max. Media Weight 80kg )
Auto Cleaning System	Positive Pressure Cleaning Anti-clogged Flash Function & Capping System
Pre-heating & Drying System	Equipped
Clamp	Equipped
Print Interface	USB2.0
Printhead Height	2 to 4 mm Above Media Adjustable
RIP Software	Maintop , UltraPrint , PhotoPrint , Topaz , Wasatch , Caldera
Input Power	AC 220V ,50Hz/60Hz
Machine Dimension	L4,300 x W800 x H1,160 mm Net Weight : 340Kg
Package Dimension	L4,450 x W870 x H1,300 mm Gross Weight : 420Kg
Operation Environment	Temperature: 20~28 ^oC Humidity: 40%~60%
