Double Row Wire to Board Connectors JST SHDL 1.00mm Pitch Housing Terminal

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SWB		Place of Origin	China
Model Number	1011 Series

Product Description

Delivery Time:7~10 work days
Certification:ISO9001/SGS/UL/RoHS/Reach

Double Row Wire to Board Connectors JST SHDL 1.00mm Pitch Housing Terminal?

Specifications:

1.0mm Pitch Wafer,10~50Pin , Housing PA66 White , Teminal Phoshphor Bronze .

Product Name	1.00mm Pitch Wire to Board Connector
Product Series	Wire to Board Connectors
SWB Part Number	1011H / 1011T / 1011W
Gender	Male
Pitch	1.00mm
No. of Rows	2
No. of Contacts	10 ~ 50
Orientation	N/A
Contact Material	Phosphor Bronze
Contact Plating	Tin Plated
Plastic Material	PA66?UL94V-0
Plastic Color	White
Current Rating	1A AC/DC
Voltage Rating	50V AC/DC
Operating Temp. Range	-25℃~+85℃
Contact Resistance	20mΩ Max
Insulation Resistance	100MΩ Min
Withstanding Voltage	500V AC/minute
Wire Range	AWG#28~32

Competitive Advantage:

Brand-name Parts Country of Origin Experienced Staff Green Product Guarantee/Warranty Perfect Packing Competitive Price High Quality Prompt Delivery Cetification: ISO9001/SGS/UL/RoHS/Reach Reputation Best Re-Sale and After-Sale Service Small Orders Accepted Free Samples Main Customers:Vestel/FOXCONN/LOGICDATA

Packaging & Shipping

1 Packaging : Useing strong bags/boxes/cartons for package to reduce the damage during the shipments. Tape and reel packing, Clamshell packing,Pallet packing etc are available .

2 Delivery Method: by sea, by air, or express such as DHL/TNT/UPS etc .

3 Delivery Time: normally 7-14days, could be negotiable when order is urgent .

Our Services

1 fully-Inspection - Products are 100% inspected before shipment
2 In case of quality discrepancy or quantity discrepancy, we will do replenishment immediately, or other better methods after negotiation, to make sure our customers could be satisfied well .
3 Solution - Find the problems, make an effective improvement, and impose more strict quality control .

4 Long term after sell service to ensure customer is satisfied .

FAQ

Q:How to place a fast connector order ?

A:The following tips will save your time .

The name of the product Pictures and/or the data sheet for the product The number of rows The number of pins per row The pitch of the connector The height of the insulator The color of the insulator The type of material Any Additional Demands

Ask your engineer for details

Are you a purchaser that doesn’t work directly with the product? To place a fast connector order, you can consult the project engineer to gather these information before contacting us.
